Soalr Led Street Light

Specifications

1.Height:6m(lamp-post:thickness:3mm,up diameter:70mm,down diameter:170mm)

Flange:300×300×12mm   light arm:800mm(up:750-800mm,down:160-170mm)

2.Light pole:all steel and hot galvanization spraying-plastic 15 years

3.Solar panel warranty time:20 years

4.Polycrystal/monocrystalline silicon:80W

5.Monocrystalline silicon solar cells 125*125mm

6.No of cells and connections

7.Dimension of module(mm)1200*535*35

8.Weight:7.5kg

9.Temperature and Coefficients

 NOCT                          48ºC ±2ºC

Current temperature coefficient         %/K    0.06±0.01

Voltage temperature coefficient          mV/K   -(78±10)

Power temperature coefficient        %/K    -(0.5±0.05)

NOTC:Nominal Operation Cell Temperature

lar battery:   1×12V/100ah                        5-8 years

11.Features:

Fully-sealed and maintenance-free   lifetime is up to 5 years

Applicable temperature:+70- -50°C

Cell packing and cover adopt ABS,

Strengthen resistance fuel(V0 grade) is available to be chosen by user. Low discharge

12.Rubber material adopts special colloid plate and partitions

13.Controller    12V/10A              5 years

14.Features: Adopting wind generator or solar panel generating energy to make battery constant voltage , control current and charge automatically. It will be at the state of protection according to the checked voltage of the battery. It will protect automatically when the current is high supplied by battery, which make your battery at the best state of charging and protection and is good to Charging saturation

Property is good, visual display, easy to operate

15.Light source  1×12V/30W   LEDs, 40000hours,  3600lm

16.Solar panel holder,  10years  All steal galvanization spraying-plastic

17. Accessory, cable lines, fastener, terminal

18.Working time: over 8 hours,Cloudy or rainy days: over 5 days

19.Container:40’HQ:light pole 128 pcs,2pcs 40’HQ light pole, 20’FT solar panel and battery

20. The distance between the lights should not be more than 35m according to the lumen
