3KW Solar Home System Off-grid
Negotiable
/ Set
1 Set(Min. Order)
- SHEN ZHEN
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | H.R.S. | |
| Model Number | HRS | Specification | Normal | |
| Application | Home | Output Voltage (V) | 12V or 110V/220V | |
| Load Power (W) | 3000W | Solar Power (W) | 3000W | |
| Work Time (h) | 20 |
Product Description
Specifications
Solar System Off-grid1. Complete system, AC & DC output.
2. Easy operation.
3. CE & ROHS certified..
Solar Home System Off-grid
| Component | Specification | Qty |
| Solar Module | 1000W Monocrystalline | 4pcs |
| Battery | 48V150ahSealed lead-acid battery | 8 pcs |
| Controller | 48V30A | 1 pcs |
| Invertor(output) | 48V to 110V/220V,1000W | 1 pcs |
| Module Bracket | Stainless steel | 4 pcs |
| Lightning arrester | 1 pcs | |
| Power Cabinet | 1 pcs |
We can design all kinds of systems basing on clinets spec/application.
| Solar Power System | |||
| 3KWp large polysilicon solar power system configuration | |||
| Solar Power Specifications | AC220V output from the two-phase polycrystalline silicon solar power system net- | Remarks | |
| Load power 3000W/AC220V, while 70% rate | |||
| Solar power per day (hours) | 6 | The load | |
| Estimates of electricity generation sunny day (W. Hr) | 13500 | That is 13.5 kWh | |
| Maximum daily load power consumption (W. Hr) | 12600 | That is 12.6 kWh | |
| Rainy days, solar power is insufficient | 2-3 days of storage power supply systems | ||
| Solar panel array | Use solar panels veneer peak power (Wp) | 150 | 72V/2.08A |
| With the number of solar panels (blocks) | 20 | ||
| The total output of solar panel array peak power (Wp) | 3000 | ||
| Single cell plate dimensions (mm) | 809 * 1581 * W long thick 40 | Veneer Weight 14kg | |
| Array of solar panels covering a total area (M2) | 39 | Panels layout plan | |
| Price per watt solar panels | |||
| Panels total price | |||
| Batteries | Selection of high quality fully sealed, maintenance-free battery specifications | DC12V | |
| Batteries | 24 | Life of 10-12 years | |
| The total capacity of battery (Ah) | 48V/300AH | Ambient temperature -55 ~ +75 °C | |
| Battery price | |||
| Other configuration | Automatically switch charge and discharge controller 1 set | Specifications DC48V/150A | |
| Sine wave inverter | DC48V/AC220V 3000W | ||
| AC output power distribution cabinet | |||
| Other costs | Solar panel array brackets, battery rack | ||
| Solar power system wiring and cable, auxiliary | |||
| 7KWp large polysilicon solar power system configuration | |||
| Solar Power Specifications | AC220V output from the two-phase polycrystalline silicon solar power system net- | Remarks | |
| Load power 7000W/AC220V, while 70% rate | |||
| Solar power per day (hours) | 6 | The load | |
| Estimates of electricity generation sunny day (W. Hr) | 31500 | Electricity that is 31 degrees | |
| Maximum daily load power consumption (W. Hr) | 29000 | Electricity that is 29 degrees | |
| Rainy days, solar power is insufficient | 2-3 days of storage power supply systems | ||
| Solar panel array | Use solar panels veneer peak power (Wp) | 200 | 72V/2.78A |
| With the number of solar panels (blocks) | 35 | ||
| The total output of solar panel array peak power (Wp) | 7000 | ||
| Single cell plate dimensions (mm) | 995 * 1646 * W long thick 50 | Veneer Weight 19.13kg | |
| Array of solar panels covering a total area (M2) | 60 | Panels layout plan | |
| Price per watt solar panels | |||
| Panels total price | |||
| Batteries | Selection of high quality fully sealed, maintenance-free lead-acid battery specifications | DC12V | |
| Batteries (unit) | 80 | Life of 10-12 years | |
| The total capacity of battery (Ah) | 48V/1500AH | Ambient temperature -55 ~ +75 °C | |
| Battery price | |||
| Other configuration | Automatically switch charge and discharge controller | Specifications DC48V/100A | |
| Sine wave inverter | DC48V/AC220V 3000W | ||
| AC output power distribution cabinet | |||
| Other costs | Solar panel array brackets, battery rack | ||
| Solar power system wiring and cable, auxiliary | |||
