Solar thermal power generation 1200W(CE,ROHS)

Specifications

1.Cell Polycrystalline silicon solar cells
2.No of cells and connections
3.low self discharge

1.Load capacity: air conditioner (KSIB009-H2161) and light (40W-100W)

2.Solar battery:1200W(5×240W)    life: 20 years

3.OPZV storage battery: 12pcs×2V/1000AH    life: 10 years

4.Solar energy controller: 36V/60AH      life: 5 years

5.Inverter: sine wave output:170–230V/50Hz/60Hz,output power:2000W   life:5 years

6.Working hours: over 10 hours per day under sunlight of 10 hours/day

7.Delivery date: 3-15days(maily depends on the size of your order

1) Specifications

  Cell                     Polycrystalline silicon solar cells 156*156mm

  No of cells and connections                     72(6*12)

  Dimension of module (mm)                     970*1925*50

  Weight                                      About  26kg

2)Temperature and Coefficients

  NOCT                                     48ºC ±2ºC

  Current temperature coefficient          %/K    0.06±0.01

  Voltage temperature coefficient          mV/K   -(155±10)

  Power temperature coefficient          %/K    -(0.5±0.05)

 NOTC: Nominal Operation Cell Temperature

3) Characteristics

 Model              JNGM260W   JNGM250W   JNGM240W   JNGM230W

 Open circuit voltage (Voc)    43.6V      43.4V         43.4V        43.2V

 Optimum operating voltage (Vmp)  35.2V    35.2 V      34.8V        34V

 Short circuit current (Isc)            7.91A    7.62A    7.41A        7.29A

 Potimum operating current(Imp)      7.39A    7.10A    6.89A       6.76A

 Maximum power at STC(Pm)         260W    250W   240W       230W

4) STC Irrandiance 1000W/m²,Module temperature 25ºC Am=1.5



4)OPZV storage battery

(1)omniseal :Adopt unique production technology and special structural. Safety and sealing guaranteed

(2)non-maintain: Unique gas can change the produced gas into water. Adsorption firber needs making up electricity in lifespan, ydraulic

3)low self discharge: slablattice Used good corrosion resistance of calcium alloy,making low self discharge minimum. 25 degrees Celsius temperature under storage,needs no recharging in an half year

4)temperature range:-10°C-40°C

5)life design Using corrosion structure of heavy calcium alloy plate, make the battery discharge life

6)applied range:solar energy system, wind energy system, UPS power system,the power transformer, small dc system of electronic equipment, portable electric tools, electric toys, alarm system, and the ship for electric batteries

Solar energy controller and inventer

5)function

MPU control/LCD display/Remote monitoring,/Multiple solar battery matrix inputs

Multiple solar battery matrix operation parameter display,

Battery current HVD charge or discharge can be set

Load current LVR turn on and off can be set

Intelligentized temperature compensation

Overload protection

Short circuit protection

Back discharge protection

Polarity protection

Thunder and light protection

Low-voltage protection

Over charge protection

IP55 protection

6)Solar energy cartridge

Adopt angle iron(5x5mm),and cover handled after ot injection

Storage battery cartridge/box

Adopt angle iron(8x8mm),and cover handled after ot injection

Battery box is adopted by all steel plate metal, sturdy and durable

7)Accessories

standard interface ,power line, fixed screw
