Home > Products > Water-Pump > 4inch High pressure fire pump Diesel Engine Driven trash pump
4inch High pressure fire pump Diesel Engine Driven trash pump
- 10000 Set / Sets per Month
- FUZHOU
- T/T
- MONO progressive block for prefabried concrete houses
- MONO progressive block for concrete pump spare parts
- MONO progressive block for ready mix concrete trucks
- MONO progressive block for concrete statue molds
- MONO progressive block for concrete columns mold
- MONO progressive block for gearbox for concrete mixer
Product Details
Place of Origin: | Fujian, China | Brand Name: | JLT,Lion King,Century Power | Model Number: | DWP50,DWP80,DWP100 |
Theory: | Centrifugal Pump | Structure: | Piston Pump | Usage: | Water |
Power: | Electric | Standard or Nonstandard: | Standard | Fuel: | Diesel |
Pressure: | Other, Low Pressure, Low Pressure | Application: | Other, Irrigation, Irrigation |
Product Description
Specifications
4inch High pressure fire pump Diesel Engine Driven trash pumpPopular for irrigation and homeuse
Large volume water discharge
4inch High pressure fire pump Diesel Engine Driven trash Pump
- Diesel water pump,garden pump,pump,
- Powered by air-cooled, 4-stroke diesel engine
- Large volume water discharge
- Highly effective mechanical seal
- Compact and light weight structure
- One year warranty
- high quality
- Aluminum alloy high pressure casting
- Full frame protection offers exceptional performance even in the toughest conditions
- Large fuel tank ensures hours of continuous running
- Pump head as same as HONDA pumps
- 5% easy broken spare parts will be provided to the buyer for free for container order
Specifications:
-
PUMP Model
DWP50 DWP80 DWP100 Suction port dia. (mm) 50 (2 in)
80 (3 in)
100 (4 in)
Max. Capacity [m3/hr] 36
60
96
Max. Head (m) 26
25
31
Self-priming time(s/4m) 80
120
180
Max. Sucition Head (m)
8
8
8
Engine Model JD170
JD178
JD186
Engine type Single-cylinder, 4-stroke, air-cooled diesel engine
Cont. Output(hp)/(rpm) 4.0 6.0 11.0 Displacement (cc)
219
306
418 Fuel tank capacity (L) 3.5
3.5
3.5
Net weight (kg)
42
50
70
Dimensions (LxWxH) 510*425*555
560*490*595
660*510*635
20ft Container QTY 236
132
114
40HQ Container QTY 492
384
320
Accessories for each water pumps:
-
Engine tool kit (1set) Standard Accessories Starter (1pc) free Hose coupling (2pcs) Hose band (3pcs)
We have own factory, then supply lower price and best quality product.
If you have need more information about this series. Please don't hesitable to contact with us.
Contact Us
- Fuzhou Jinlongteng Power Engine & Machinery Co., Ltd.
- Contact nameJoJo Zeng
- Phone86-189-50495106
- AddressNO.8 HeJin Road ,WuHu Mountain Industrial Zone,Fuzhou,Fujian,China Fuzhou,Fujian
