100kva small water cooled diesel generator price in india

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Supply Ability 200 Piece / Pieces per Month
Port FUZHOU
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Fujian, China	Brand Name	JLT
Model Number	C20-1000	Output Type	AC Three Phase
Speed	1500/1800	Frequency	50/60HZ
Rated Power	20kw to 1000kw	Rated Voltage	220/380V,230/400V,110/208V,127/220
Rated Current	Depend on the power

Product Description

Specifications

diesel power genrator
20kw-1000kw
Open or silent type
One year warranty

diesel power generator

Genset	Prime Power	Standby Power	Engine Model	Fuel Consumption	Dimension	Weight
Model	KW/KVA	KW/KVA	Engine Model	≤g/kw.h	mm	Kg
C20	20/25	22/27.5	4B3.9-G2	228	16087301184	710
C30	30/38	33/41	4BT3.9-G2	214	16707301232	770
C40	40/50	44/55	4BTA3.9-G2	216	16707301232	800
C45	45/56	50/62	4BTA3.9-G2	216	17057301310	830
C80	80/100	88/110	6BT5.9-G2	214	21508301380	1400
C100	100/125	110/137	6BTAA5.9-G2	211	22308501450	1480
C120	120/150	132/165	6CTA8.3-G2	210	24508601600	1780
C145	145/180	160/192	6CTA8.3-G2	210	24508601600	1800
C160	160/200	176/220	6CTAA8.3-G2	205	24709401600	1950
C200	200/250	220/275	6LTAA8.9-G2	197	25709501600	2150
C200	200/250	220/275	NT855-GA	192	300010501750	3000
C200	200/250	220/275	MTA11-G2A	200	300010501750	3000
C220	220/275	250/310	NTA855-G1A	195	300010501750	3100
C250	250/310	275/344	MTAA11-G3	188	300010501750	3220
C275	275/344	300/375	NTA855-G2A	200	300010501750	3300
C300	300/375	330/415	NTA855-G7A	205	310011501700	3450
C360	360/450	396/495	KTA 19-G3	207	320014001900	4300
C400	400/500	440/550	KTA 19-G4	206	330014002000	4450
C500	500/625	550/688	KTA A19-G6A	206	350019202250	4700
C600	600/750	660/825	KTA 38-G2	216	430017502400	6750
C720	720/900	800/1000	KTA 38-G2A	203	430017502400	6950
C800	800/1000	880/1100	KTA 38-G5	205	446019002400	8300
C1000	1000/1250	1100/1375	KTA 50-G3	213	556020502310	10900

Genset:
1)Power range: 8kw-1000kw
2)110V-480V,50HZ/60HZ
3)phase,4wire,12leads
4)Single/three phase
5)water cooled/air cooled
6)Silent/weather proof/trailer type
7)Fuel tank for at least 8H running
8)Two 12V batteries
9)24V charge alternator
10)50 degree C Radiator

Engine:
1)Engine:Deutz,Volvo,Dawoo,MTU and Chinese famous

water-cooled diesel engines
2)50HZ or 60HZ
3)2,3,4,6,12 cylinders
4)low fuel consumption
5)Rated power factor:0.8(lagging)
6)102/120,114/135,140/152,159/159mm bore/stroke
7)standard starting method:24V electric starting
8)cooling method: closed water-cooled
9)lubricating methond:colsed lubricating

Alternator:
1)Alternator:Stamford/OEM Stamford/other blands brushless alternator
2)CLASS H insulation
3)IP23 protection
4)self-regulator by AVR
5)50hz /1500rpm or 60hz/1800rpm
6)110-480V,3 phase,4wire,pf.0.8
7)electric system:24V/12V
8)wave distort:less then 10%

Control panel:
1)Automatic control panel(AMF),LED display.
2)Four protection systems
3)Emergency stop
4)DSE/COMAP/SMARTGEN/HARSON series controller

Optional:
1)Trailer type
2)Soundproof / water proof
3)ATS(automatic transfer switch)
4)water Heater
5)Parallel system
6)Remote system
