Silent Diesel Power Generators Prices in Pakistan

Silent Diesel Power Generators Prices in Pakistan thumbnail-1
Silent Diesel Power Generators Prices in Pakistan photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
JLT
Model Number:
C20-1000
Contact Supplier Request Quote Chat Now
Fuzhou Jinlongteng Power Engine & Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
FUZHOU
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name JLT
Model Number C20-1000
Output Type AC Three Phase
Speed 1500/1800
Frequency 50/60HZ
Rated Power 20kw to 1000kw
Rated Voltage 220/380V,230/400V,110/208V,127/220
Rated Current Depend on the power

Specifications

diesel power genrator
20kw-1000kw
Open or silent type
One year warranty

 silent diesel power generators prices in pakistan



diesel power generator



Genset Prime Power Standby Power Engine Model Fuel Consumption Dimension Weight
Model KW/KVA KW/KVA ≤g/kw.h mm Kg
C20 20/25 22/27.5 4B3.9-G2 228 1608*730*1184 710
C30 30/38 33/41 4BT3.9-G2 214 1670*730*1232 770
C40 40/50 44/55 4BTA3.9-G2 216 1670*730*1232 800
C45 45/56 50/62 4BTA3.9-G2 216 1705*730*1310 830
C80 80/100 88/110 6BT5.9-G2 214 2150*830*1380 1400
C100 100/125 110/137 6BTAA5.9-G2 211 2230*850*1450 1480
C120 120/150 132/165 6CTA8.3-G2 210 2450*860*1600 1780
C145 145/180 160/192 6CTA8.3-G2 210 2450*860*1600 1800
C160 160/200 176/220 6CTAA8.3-G2 205 2470*940*1600 1950
C200 200/250 220/275 6LTAA8.9-G2 197 2570*950*1600 2150
C200 200/250 220/275 NT855-GA 192 3000*1050*1750 3000
C200 200/250 220/275 MTA11-G2A 200 3000*1050*1750 3000
C220 220/275 250/310 NTA855-G1A 195 3000*1050*1750 3100
C250 250/310 275/344 MTAA11-G3 188 3000*1050*1750 3220
C275 275/344 300/375 NTA855-G2A 200 3000*1050*1750 3300
C300 300/375 330/415 NTA855-G7A 205 3100*1150*1700 3450
C360 360/450 396/495 KTA 19-G3 207 3200*1400*1900 4300
C400 400/500 440/550 KTA 19-G4 206 3300*1400*2000 4450
C500 500/625 550/688 KTA A19-G6A 206 3500*1920*2250 4700
C600 600/750 660/825 KTA 38-G2 216 4300*1750*2400 6750
C720 720/900 800/1000 KTA 38-G2A 203 4300*1750*2400 6950
C800 800/1000 880/1100 KTA 38-G5 205 4460*1900*2400 8300
C1000 1000/1250 1100/1375 KTA 50-G3 213 5560*2050*2310 10900





Genset:
1)Power range: 8kw-1000kw
2)110V-480V,50HZ/60HZ
3)phase,4wire,12leads
4)Single/three phase
5)water cooled/air cooled
6)Silent/weather proof/trailer type
7)Fuel tank for at least 8H running
8)Two 12V batteries
9)24V charge alternator
10)50 degree C Radiator

Engine:
1)Engine:famous water-cooled diesel engines

2)50HZ or 60HZ
3)2,3,4,6,12 cylinders
4)low fuel consumption
5)Rated power factor:0.8(lagging)
6)102/120,114/135,140/152,159/159mm bore/stroke
7)standard starting method:24V electric starting
8)cooling method: closed water-cooled
9)lubricating methond:colsed lubricating

Alternator:
1)Alternator:Stamford/OEM Stamford/other blands brushless alternator
2)CLASS H insulation
3)IP23 protection
4)self-regulator by AVR
5)50hz /1500rpm or 60hz/1800rpm
6)110-480V,3 phase,4wire,pf.0.8
7)electric system:24V/12V
8)wave distort:less then 10%


Control panel:
1)Automatic control panel(AMF),LED display.
2)Four protection systems
3)Emergency stop
4)DSE/COMAP/SMARTGEN/HARSON series controller



Optional:
1)Trailer type
2)Soundproof / water proof
3)ATS(automatic transfer switch)
4)water Heater
5)Parallel system
6)Remote system

silent diesel power generators prices in pakistan



 silent diesel power generators prices in pakistan

silent diesel power generators prices in pakistansilent diesel power generators prices in pakistansilent diesel power generators prices in pakistan
