Gasoline Generator (XGGF3500E)

Name: Gasoline Generator (XGGF3500E)
Brand: Shuang Tong
SKU: 143509994
Availability: InStock

Guangxi Dingbo Generator Set Manufacturing Co.,Ltd

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

Shuang Tong

Place of Origin:

China

Model Number:

XGGF3500E

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai, Shenzhen

Delivery Detail:

30 days

Brand Name Shuang Tong

Place of Origin China

Model Number XGGF3500E

Rated Current 12.2(A)

Output Type AC Single Phase

Speed 3000r/min

Frequency 50(Hz)

Rated Voltage 230(V)

Rated Power 2.8KVA

Gasoline Generator Data
Set Type				XGGF3500E
	Rated Frequency		HZ	50
	Rated Output Power		KVA	2.8
	Maximum Output Power		KVA	3.2
	Rated Voltage		V	230
	Rated Current		A	12.2
	Rated Speed		r/min	3000
Generator	Generator Type			KT-3
	Pole Number			2
	Phase Number			Single
	Excitation Mode			Self Excitation
	Power Factor		COSΦ	1.0
	Insulation Class			B
Engine	Type			XG178FG
	Cylinder Type			One Cylinder,4 stroke,Air cooled,Direct Injection
	Bore×Stroke		mm	78×62
	Gross Displacement		ml	296
	Compression Ratio			20∶1
	Rated Power		KW	3.68
	Lubrication method			Pressure Spray
	Lubrication Type			CD30
	Lubrication Capacity		L	1.1
	Starting method			Recoil hand starting or Electrical Starting
	Star Motor Capacity		V-KW	12V 0.8KW
	Charge Alternator Capacity		V-A	12V 3A
	Accumulator Capacity×Number		V-Ah	12V 36Ah
	Fuel Type			Gas
	Fuel Consumption Rate		g/KW.h	≤370
Set	Panel Style			Common
	Output	Voltage	V	115/230
		Socket		Two Singe Phase Socket
		Binding post		No
		DC12V Output		Binding Post Output
	Noise（7m）		dB(A)	77
	Structural style			Open
	Fuel capacity		L	13.5
	Continuous Running Time		h	8.5
	Overall Size		mm	655×480×530
	Net Weight		kg	X：65 E:70
Packing	Packing Material			Carton
	Carton Size		mm	695×520×575
