Gasoline Generator

Name: Gasoline Generator
Brand: Shuang Tong
SKU: 143509702
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

Shuang Tong

Place of Origin:

China

Model Number:

XGGF6500E

Guangxi Dingbo Generator Set Manufacturing Co.,Ltd

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai, Shenzhen

Delivery Detail:

30 days

Brand Name Shuang Tong

Place of Origin China

Model Number XGGF6500E

Rated Current 19.6A

Output Type AC Single Phase

Speed 3000r/min

Frequency 50(Hz)

Rated Voltage 230V

Rated Power 4.5KVA

Gasoline Generator Set
Set Type	XGGF6500E
Rated Frequency	50 Hz
Rated Output Power(KVA)	4.5
Maximum Power (KVA)	5.0
Rated Voltage(V)	230
Rated Current(A)	19.6
Rated Speed	3000
Circuit Mode	Single-phase Three Loop
Power Factor	1.0
Insulation Class	B
Number of Poles	2
Excitation Mode	Self-excitation constant voltage (AVR)
Panel Type	X/E/T:Ordinary Panel TA: Smart Panel
Output Voltage	115/230 120/240
Output Jack	Two Jacks
Output Terminal	None
DC12V output	Terminal Output
Outline Dimension: Long x width x height	X/E 720×492×650
Net Weight (kg)	100
Gross Weight (kg)	115
Noise (7m)dB(A)	77
Structural Style	Open-shell
Model	KM186FA
Type	Single – cylinder, Vertical, Four Strokes, Direct Injection
Number of Cylinders – Bore x Stroke	1-86×72
Total Displacement (ml)	418
Rated Power (KW)	5.7/3000
Compression Ratio	19:1
Rated Speed r/min	3000
Cooling Way	Air Cooling
Lubrication Method	Pressure Splash Type
Starting Mode	X type, Recoil Starter E/T/TA type, Electric Starting
Fuel	0# (Summer), -10# (Winter), -35# (Severe Cold)
Lubricating Oil	SAE10W30 (Over CD class)
Lubricating Oil Capacity (L)	1.65
Starting Motor Capacity (V-KW)	12V 0.8KW
Charging Generator Capacity (V-A)	12V 3A
Battery Capacity (V-Ah)	12V 36AH
Fuel Consumption Rate g/KW.h	275.1 281.5
Genset Fuel Tank Capacity (L)	X/E:15
Genset continuous Running Time (h)	X/E:8
