Help CenterCNC Plate Sheet Punching Machine
Related Products
-
Four Column Hydraulic PressNegotiableMOQ: 1 Set -
HD-Y27 Series Single-Action Hydraulic Sheet-stamping Press MachineNegotiableMOQ: 1 Set
-
HD-Y28 Series Double-Action Hydraulic Sheet-Stamping Press MachineNegotiableMOQ: 1 Set
-
Y28 1300 Ton Double Action Drawing Press MachineNegotiableMOQ: 1 Set
-
Hydraulic Busbar Cutting Punching Bending MachineNegotiableMOQ: 1 Set
Production Details:
It is suitable for using in screen mesh, can making, bottle cap, electrical control box,motor, electrical appliance, look,instrument, construction and decorative material hardware,car and bicycle parts.
Production Features:
Independent wto-dimension coordinate shaft,each shaft may set speed, acceler-ation and deceleration time.
Abundant diagnostic function, every switch can be real-time monitored.
Easy usage and programmable.
Ac servo motor or step motor drive and lock.
Program power-off protection.
Over current, over voltage and overheat protection.
Adopt high performance controller,man-machine creen interface, easy operating.
Adopt imported ball screw,ball gib, step motor or serve motor which have long life and high precision,low failure rate and easy to maintenance.
Fixed on deep throat press to be an economic CNC step punch pres.
Other specification:
| Model | Description (mm) |
Dimension (mm) |
Weight (kg) |
| NCPF100 | 1000×1000 | 1500×1700×1000 | 900 |
| NCPF125 | 1000×1250 | 1750×1700×1000 | 1000 |
| NCPF200 | 1000×2000 | 2500×1700×1000 | 1300 |
| NCPF250 | 1000×2500 | 3000×2000×1000 | 1500 |
| Item | Step Motor | AC ervo Motor |
| Feed Precision (mm) |
±0.15 | ±0.10 |
| Max. Feed Speed (m/min) |
12 | 30 |
| Programm Memory (k) |
8 | 8 |
| Voltage (v) |
220 | 380 |
| Rated Power (kw) |
1 | 3 |
| Man Machine Interface | Screerinterface | screerinterface |
| Max Step Length In Continuous Stroke | ||||||
| Stroke Per Minute(spm) | 45 | 70 | 90 | 100 | 110 | 120 |
| Max Step Length(mm) | 210 | 150 | 110 | 100 | 90 | 60 |
