CNC Plasma Cutting Machine
Specifications
1.Quick data transmission 2.High efficient and carefree operation
3.Economical
Model Processing Scale
XHSD-1325 1300x2500mm
XHSD-1330 1300x3000mm
XHSD-1530 1500x3000mm
XHSD-1540 1500x4000mm
XHSD-2060 2000x6000mm
Main technical parameters:
1. Maximum operational speed: 15,000mm/min
2. Cutting precision: ±1‰
3. Repositioning precision: ±0.01mm
4. Maximum torch lifting distance: 120mm
5. Input voltage: 220V/380V/50HZ
6. Weight: 1,000KG
Characteristics:
1. Advanced XHSD plasma numerical controlled system, completely offline work and human-oriented
operation;
2. Several software compatibility: compatible with CorelDraw, AutoCAD, Wentai and other software;
3. Equipped with infrared positioning device to assure processing and re-positioning precision;
4. Highly efficient and carefree operation: continuous carving against power failure and breakpoint,
estimate of processing time, automatic tool aligning, real human-oriented design;
5. Linear motion guide to guarantee the cut of work piece is vertical with high precision and without
nodulation;
6. The machine structure is rational with crossbeam using standard profile; it works with optical
coupler isolation
control and features super-strong anti-interference capability;
7. It could cut aluminum, steel, iron, copper, and Ti-gold sheet as well as other conductive metals
with high efficiency;
8. Fine mesh net and waste collection drawer contribute to work convenience while automatic dust
vacuum system
makes work environment cleaner;
9. It could be equipped with Hypertherm plasma generator imported from America or plasma generator
made in China as required by users;
10. It is optional on servo system, driving system, working platform and dust collection device. Besides,
full version of authentic software would come with the machine.
Application:
Outer frame processing of electromechanical products, advertising signs, decoration, garden iron art,
vehicle manufacturing, ship building, electric appliances, metal plate materials cutting and other industries.
