Home > Products > Cuplock Scaffolding > Painted/Galvanized Cuplock Scaffolding System,Construction Scaffolding System
Painted/Galvanized Cuplock Scaffolding System,Construction Scaffolding System
- 10000 Piece / Pieces per Month
- QINGDAO
- T/T
- High Quality Steel Tubular Scaffolding Cuplock Scaffolding
- Cuplock Scaffolding /Scaffolding System Scaffold/Construction Scaffolding
- Cuplock Scaffold for Scaffold System
- Scaffold Materials Cuplock/Cuplock Scaffolding For Construction
- safe cuplock scaffolding, cuplcok scaffolding system
- Painted metal cuplock construction scaffolding
Product Details
Place of Origin: | Shandong, China | Brand Name: | QUEEN | Model Number: | CQ |
Type: | Scaffolding Parts | Scaffolding Part Type: | Scaffolding Frames |
Packaging Details
Steel pallet
Product Description
Specifications
Painted/Galvanized Cuplock Scaffolding System,Construction Scaffolding1)Raw materia:Q235/Q345
2)Size of pipe:48.3*3.25mm
Painted/Galvanized Cuplock Scaffolding System,Construction Scaffolding System
Product Description:
Cuplock scaffolding system is the most widely used scaffolding system. This kind scaffolding is 20% lighter and 30% faster than the traditional ones. It is compoesd of ledger, standard, cross brace and scaffolding accessories. The standard contains up bowl, bottom bowl and the fixed pin.
Specification:
1)Raw material:Q235/Q345
2)Size of pipe:48.3*3.25mm
3)Surface finish:Powder coated/galvanized/HDG
Item Name | Cuplock Scaffolding | |
Brand Name | Queen | |
Raw Material | Q235 /Q345steel Grade | |
Components | Standard.Ledger .Diagonal brace. Top/Bottop Cup/ Ledge Blade | |
Surface finish | Electric Galvanized/HDG/Powder coated | |
Size | Pipe size:48.3mm | |
Thickness:3.25mm | ||
Usage | Widely used in Bridge .Tunnel.Peterifaction.Shipbuilding .railway,Airport. Dock Industry and Civil Building | |
Packing | By Steel pallet or bulk | |
Standard | 48.3*3.25*500mm | 3.5kg |
48.3*3.25*1000mm | 5.6kg | |
48.3*3.25*1300mm | 8.0kg | |
48.3*3.25*1500mm | 8.75kg | |
48.3*3.25*1800mm | 10.6kg | |
48.3*3.25*2000mm | 11.4kg | |
48.3*3.25*2500mm | 14.0kg | |
48.3*3.25*3000mm | 16.70kg | |
8.3*3.25*4000mm | 20.36kg | |
Ledger | 48.3*3.25*650mm | 2.54kg |
48.3*3.25*914mm | 3.6kg | |
48.3*3.25*1065mm | 4.10kg | |
48.3*3.25*1150mm | 4.7kg | |
48.3*3.25*1570mm | 5.76kg | |
48.3*3.25*1829mm | 6.62kg | |
48.3*3.25*2130mm | 7.62kg | |
48.3*3.25*2438mm | 8.24kg | |
48.3*3.25*3050mm | 10.68kg | |
Diagonal brace | 48.3*3.25*915mm | 3.4kg |
48.3*3.25*1150mm | 4.04kg | |
48.3*3.25*1572mm | 5.34kg | |
48.3*3.25*1829mm | 6.13kg | |
48.3*3.25*2130mm | 7.06kg | |
48.3*3.25*2438mm | 8.01kg | |
48.3*3.25*3050mm | 9.90kg | |
Steel Plank | 210*45*1.2*1000/2000/3000/4000 | |
250*50*1.2*1000/2000/3000/4000 | ||
Screw jack base | 38*4.0*500mm | 3.35kg |
38*4.0*600mm | 3.65kg | |
48*4.0*600mm | 4.4kg | |
35*500mm | 4.5kg |
Product Display:
Workshop:
Packing& Shipping:
Main Business:
1 Scaffolding:
We can supply you: Kwikstage scaffolding and accessories, Ringlock scaffolding and accessories, Cup lock scaffolding and accessories; Frame scaffolding and accessories and Four-way scaffolding and accessories.
2 Couplers/Clamps:
The couplers we can manufacture include: British type couplers, Italian type couplers, German type couplers, American type couplers, and many other kinds of couplers as per your drawings.
3 Props
Quality shoring props of different specifications can be manufactured in our factory.
4 Others
We can also manufacture fences, ladders, steel trays and other related products that are needed in the construction of scaffolding.
About Us:
We specialize in the field of scaffolding systems for 10 years and we can supply many kinds of the Scaffolding, such like Ringlock scaffolding, Cuplock scaffolding, Kwikstage scaffolding and so on.We just want to emphasize that we earn the good reputation in the market due to the competitive price and the high quality. Please do not hesitate to contact us and we are confident and committed to providing you with the best quality and service all the time.
WELCOME TO OUR FACTORY.
Company Profile
Since 2000, we has been specialized in manufacturing scaffoldings, kwik stage/ringlock/cuplock/frame scaffoldings, steel planks, couplers, accessories & formwork parts, and hardware, ratchet wrench tools, garden tools, sockets and accessories. We expand our products to hand tools, automotive tools, etc. We have more than 10 years of production and export experience. Each tool produced by Queen is in the best quality, with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of markets around the world.
We have a highly experienced producing team, which maintains top level of every stage of the producing progress. Each team of workers is led by supervisor who monitors day to day works. Automated welding and robot systems are widely used.
Today, we have customers in over 35 countries around the world. Our products are engineered for safety, strength and flexibility to meet international standards within this industry. It is important for structural engineers, scaffolding factories and formwork specialists. In terms of working processes, we have expertise in iron casting, steel forging and thread rolling. We have a complete quality control system, which guarantees the high quality of our products and makes sure all progress is made to schedule.
With all our technical knowledge and capacity, if you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationships with new clients in the near future.
