Specifications
High Quality Steel Tubular Scaffolding Cuplock Scaffolding1)Raw materia:Q235/Q345
2)Size of pipe:48.3*3.25mm
High Quality Steel Tubular Scaffolding Cuplock Scaffolding
Product Description:
Cuplock scaffolding system is the most widely used scaffolding system. This kind scaffolding is 20% lighter and 30% faster than the traditional ones. It is compoesd of ledger, standard, cross brace and scaffolding accessories. The standard contains up bowl, bottom bowl and the fixed pin.
Specification:
1)Raw material:Q235/Q345
2)Size of pipe:48.3*3.25mm
3)Surface finish:Powder coated/galvanized/HDG
Item Name | Cuplock Scaffolding | |
Brand Name | Queen | |
Raw Material | Q235 /Q345steel Grade | |
Components | Standard.Ledger .Diagonal brace. Top/Bottop Cup/ Ledge Blade | |
Surface finish | Electric Galvanized/HDG/Powder coated | |
Size | Pipe size:48.3mm | |
Thickness:3.25mm | ||
Usage | Widely used in Bridge .Tunnel.Peterifaction.Shipbuilding .railway,Airport. Dock Industry and Civil Building | |
Packing | By Steel pallet or bulk | |
Standard | 48.3*3.25*500mm | 3.5kg |
48.3*3.25*1000mm | 5.6kg | |
48.3*3.25*1300mm | 8.0kg | |
48.3*3.25*1500mm | 8.75kg | |
48.3*3.25*1800mm | 10.6kg | |
48.3*3.25*2000mm | 11.4kg | |
48.3*3.25*2500mm | 14.0kg | |
48.3*3.25*3000mm | 16.70kg | |
8.3*3.25*4000mm | 20.36kg | |
Ledger | 48.3*3.25*650mm | 2.54kg |
48.3*3.25*914mm | 3.6kg | |
48.3*3.25*1065mm | 4.10kg | |
48.3*3.25*1150mm | 4.7kg | |
48.3*3.25*1570mm | 5.76kg | |
48.3*3.25*1829mm | 6.62kg | |
48.3*3.25*2130mm | 7.62kg | |
48.3*3.25*2438mm | 8.24kg | |
48.3*3.25*3050mm | 10.68kg | |
Diagonal brace | 48.3*3.25*915mm | 3.4kg |
48.3*3.25*1150mm | 4.04kg | |
48.3*3.25*1572mm | 5.34kg | |
48.3*3.25*1829mm | 6.13kg | |
48.3*3.25*2130mm | 7.06kg | |
48.3*3.25*2438mm | 8.01kg | |
48.3*3.25*3050mm | 9.90kg | |
Steel Plank | 210*45*1.2*1000/2000/3000/4000 | |
250*50*1.2*1000/2000/3000/4000 | ||
Screw jack base | 38*4.0*500mm | 3.35kg |
38*4.0*600mm | 3.65kg | |
48*4.0*600mm | 4.4kg | |
35*500mm | 4.5kg | |
Product Display:
Workshop:
Packing& Shipping:
Main Business:
1 Scaffolding:
We can supply you: Kwikstage scaffolding and accessories, Ringlock scaffolding and accessories, Cup lock scaffolding and accessories; Frame scaffolding and accessories and Four-way scaffolding and accessories.
2 Couplers/Clamps:
The couplers we can manufacture include: British type couplers, Italian type couplers, German type couplers, American type couplers, and many other kinds of couplers as per your drawings.
3 Props
Quality shoring props of different specifications can be manufactured in our factory.
4 Others
We can also manufacture fences, ladders, steel trays and other related products that are needed in the construction of scaffolding.
About Us:
We specialize in the field of scaffolding systems for 10 years and we can supply many kinds of the Scaffolding, such like Ringlock scaffolding, Cuplock scaffolding, Kwikstage scaffolding and so on.We just want to emphasize that we earn the good reputation in the market due to the competitive price and the high quality. Please do not hesitate to contact us and we are confident and committed to providing you with the best quality and service all the time.
WELCOME TO OUR FACTORY.
