Cuplock Scaffolding / Cuplock Scaffolding Parts / Cuplock Scaffolding Standard
- 10000 Piece / Pieces per Month
- QINGDAO
- T/T Credit Card
- Heavy Duty Steel Tubular Cuplock Scaffolding
- High Load Capacity Cuplock Scaffolding Mainly Used for Building Bridges ,Tunnels
- Highly Demanded Of Ganlvnized Steel Cuplock Scaffolding
- Cup-lock Scaffolding / Cup-lock System, Scaffolding
- Painted/Galvanized Cuplock Scaffolding System,Construction Scaffolding System
- High Quality Steel Tubular Scaffolding Cuplock Scaffolding
Product Details
Place of Origin: | Shandong, China | Brand Name: | QUEEN | Model Number: | MV |
Packaging Details
by steel pallet
Product Description
Specifications
Cuplock Scaffold / Cuplock Scaffold Parts / Cuplock Scaffolding Standard1)Raw material:Q235/Q345
2)Size of pipe:48.3*3.25mm
Cuplock Scaffold/ Cuplock Scaffold Parts
Specification:
1. Cuplock scaffolding system has high flexibility and high loading capacity. And it is mainly used to build bridges, tunnels, metro stations, and etc.
2. Cuplock scffolding is made by Q235 steel which is strong and durable.
3. A complete cuplock scaffolding system includes standards, ledgers, or diagonal braces.
4. The accessories of cuplock scaffolding system are cantilever bracket, side bracket, ladder bracket, ladder, intermediate, and etc.
5. One standard is welded an up cup and a bottom cup in every 500mm to join ledgers at different
heights.
6. One ledger is welded a ledger blade on both ends.
Item Name | Cuplock Scaffolding | |
Brand Name | Queen | |
Raw Material | Q235 /Q345steel Grade | |
Components | Standard.Ledger .Diagonal brace. Top/Bottop Cup/ Ledge Blade | |
Surface finish | Electric Galvanized/HDG/Powder coated | |
Size | Pipe size:48.3mm | |
| Thickness:3.25mm | |
Usage | Widely used in Bridge .Tunnel.Peterifaction.Shipbuilding .railway,Airport. Dock Industry and Civil Building | |
Packing | By Steel pallet or bulk |
|
Standard | 48.3*3.25*500mm | 3.5kg |
| 48.3*3.25*1000mm | 5.6kg |
| 48.3*3.25*1300mm | 8.0kg |
| 48.3*3.25*1500mm | 8.75kg |
| 48.3*3.25*1800mm | 10.6kg |
| 48.3*3.25*2000mm | 11.4kg |
| 48.3*3.25*2500mm | 14.0kg |
| 48.3*3.25*3000mm | 16.70kg |
| 8.3*3.25*4000mm | 20.36kg |
Ledger | 48.3*3.25*650mm | 2.54kg |
| 48.3*3.25*914mm | 3.6kg |
| 48.3*3.25*1065mm | 4.10kg |
| 48.3*3.25*1150mm | 4.7kg |
| 48.3*3.25*1570mm | 5.76kg |
| 48.3*3.25*1829mm | 6.62kg |
| 48.3*3.25*2130mm | 7.62kg |
| 48.3*3.25*2438mm | 8.24kg |
| 48.3*3.25*3050mm | 10.68kg |
Diagonal brace | 48.3*3.25*915mm | 3.4kg |
| 48.3*3.25*1150mm | 4.04kg |
| 48.3*3.25*1572mm | 5.34kg |
| 48.3*3.25*1829mm | 6.13kg |
| 48.3*3.25*2130mm | 7.06kg |
| 48.3*3.25*2438mm | 8.01kg |
| 48.3*3.25*3050mm | 9.90kg |
Steel Plank | 210*45*1.2*1000/2000/3000/4000 |
|
| 250*50*1.2*1000/2000/3000/4000 |
|
Screw jack base | 38*4.0*500mm | 3.35kg |
| 38*4.0*600mm | 3.65kg |
| 48*4.0*600mm | 4.4kg |
| 35*500mm | 4.5kg |
Product Display:
Workshop
Packing&Shipping:
Main Products:
1 Scaffolding:
We can supply you: Kwikstage scaffolding and accessories, Ringlock scaffolding and accessories, Cup lock scaffolding and accessories; Frame scaffolding and accessories and Four-way scaffolding and accessories.
2 Couplers/Clamps:
The couplers we can manufacture include: British type couplers, Italian type couplers, German type couplers, American type couplers, and many other kinds of couplers as per your drawings.
3 Props
Quality shoring props of different specifications can be manufactured in our factory.
4 Others
We can also manufacture fences, ladders, steel trays and other related products that are needed in the construction of scaffolding.
WELCOME TO OUR FACTORY.
Company Profile
Since 2000, we has been specialized in manufacturing scaffoldings, kwik stage/ringlock/cuplock/frame scaffoldings, steel planks, couplers, accessories & formwork parts, and hardware, ratchet wrench tools, garden tools, sockets and accessories. We expand our products to hand tools, automotive tools, etc. We have more than 10 years of production and export experience. Each tool produced by Queen is in the best quality, with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of markets around the world.
We have a highly experienced producing team, which maintains top level of every stage of the producing progress. Each team of workers is led by supervisor who monitors day to day works. Automated welding and robot systems are widely used.
Today, we have customers in over 35 countries around the world. Our products are engineered for safety, strength and flexibility to meet international standards within this industry. It is important for structural engineers, scaffolding factories and formwork specialists. In terms of working processes, we have expertise in iron casting, steel forging and thread rolling. We have a complete quality control system, which guarantees the high quality of our products and makes sure all progress is made to schedule.
With all our technical knowledge and capacity, if you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationships with new clients in the near future.
