Product Details
Place of Origin: | Zhejiang, China | Brand Name: | Reepure | Model Number: | micro-duct reducing connector MRC-8/6-5/3.5 |
Product Description
micro-duct reducing connector
The micro-duct reducing connectors make splicing MicroDuct fast and easy. Simply push the MicroDucts into the center of the micro-duct reducing connector. No tools are required. The micro-duct reducing connectors can be connected and disconnected 10 times and still maintain the high performance requirements for air blown installation systems.
Micro-duct reducing connectors operate at 15 BAR (218 psi) with a maximum permissible leakage rate of 1cc/min. This is equivalent to 1 bubble every 3 seconds. Higher pressures have been used in the field with no increase in leakage rate. Quick Burst rating is 25 BARS (363 psi).
micro-duct reducing connector Feature:
Body Material: | PC, impact resistant |
Collect Material: | POM, stainless steel teeth |
O-rings Material: | Nitrile rubber |
Blowing Pressure: | 16 bar |
Burst Pressure: | 25 bar |
Temperature Range: | -10 ~ 60°C |
Insertion force: | 50N max (5kg) |
micro-duct reducing connector Specification:
Reepure code | Description |
MRC-5/3.5-3/2.1 | 5-3mm straight connector, bore 2.1mm |
MRC-7/5.5-3/2.1 | 7-3mm straight connector, bore 2.1mm |
MRC-7/5.5-5/3.5 | 7-5mm straight connector, bore 3.5mm |
MRC-8/6-3/2.1 | 8-3mm straight connector, bore 2.1mm |
MRC-8/6-5/3.5 | 8-5mm straight connector, bore 3.5mm |
MRC-10/8-7/5.5 | 10-7mm straight connector, bore 5.5mm |
MRC-10/8-8/6 | 10-8mm straight connector, bore 6mm |
MRC-12/10-7/5.5 | 12-7mm straight connector, bore 5.5mm |
MRC-12/10-8/6 | 12-8mm straight connector, bore 6mm |
MRC-12/10-10/8 | 12-10mm straight connector, bore 8mm |
MRC-12.7/10-10/8 | 12.7-10mm straight connector, bore 8mm |
MRC-14/12-10/8 | 14-10mm straight connector, bore 8mm |
MRC-14/12-12/10 | 14-12mm straight connector, bore 10mm |
MRC-16/12-12/10 | 16-12mm straight connector, bore 10mm |
MRC-16/12-14/10 | 16-1414mm straight connector, bore 10mm |
MRC-18/14-14/10 | 18-14mm straight connector, bore 10mm |
1. Can I get some samples?
Yes, Sample order is available for quality test and market test .But you have to pay the postage. And we can return to you when you place formal order.
2. What’s delivery time?
It usually takes about 3-5 working days for small order and 10 days for big order when receiving your purchasing order.
3. What’s your payment terms?
We usually accept all kinds of payment terms .Such as T/T,L/C, Western Union.Cash.
4. What’s your warranty terms?
We offer 12 months warranty time .
5. Do you have the products in stock?
Depends on your request ,We have standard models in stock. Some special products and big order will be quickly produced according to your order .
6. Can I mix different power in one container ?
Yes ,Different models can be mixed up in one container ,even one order .
7. How does your factory do the quality control?
Quality is priority ,we always attach the importance to quality control from the beginning to the end of the production. Every product will be fully assembled and carefully tested before packing and shipping .
8. I would like to know if you have a partner for export?
Yes .Reepure have the right to export and can sell product all over the world .
9. How can I trust you ?
The core of Reepure is honesty and loyalty. our company has been audited and approved ISO9001,Rohs certification. Assessment report will could be sent to you by e-mail. Now we have clients all around the world .
