Home > Products > Digital measuring instruments > surface roughness tester
surface roughness tester
USD $480 - $510
/ Piece
1 Piece(Min.Order)
- 500 Piece / Pieces per Month
- Shanghai
- T/T D/P D/A Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | LAND | |
| Model Number | KBD-6200 | Power | Electronic | |
| Usage | Process Testing Machine |
Product Description
Specifications
Surface roughness tester can be supplied to our customers1.FEATURES
This instrument is compatible with four standards of
ISO, DIN, ANSI and JIS and is widely used in production
site to measure surface roughness of various
machinery-processed parts, calculate corresponding
parameters according to selected measuring conditions
and clearly display all measurement parameters.
When measuring the roughness of a surface, the
sensor is placed on the surface and then uniformly
slides along the surface by driving the mechanism
inside the tester. The sensor gets the surface roughness
inside the tester. The sensor gets the surface roughness
by the sharp built-in probe. This roughness causes
displacement of the probe which results in change of
inductive amount of induction coils so as to generate
analogue signal, which is in proportion to the surface
roughness at output end of phase-sensitive rectifier.
The exclusive DSP processes and calculates and then
outputs the measurement results on LCD.
* Very easy to operate
* Multiple parameter measurement: Ra, Rz
* Highly sophisticated inductance sensor
* Built-in lithium ion rechargeable battery and control
circuit with high capacity
* Small in size, light in weight and easy to use
* Can communicate with PC computer for statistics,
printing and analysing by the optional cable and the
software for RS232C interface.
*Manual or automatic shut down. The tester can be
switched off by pressing the Power key at any time.
On the other hand, the tester will power itself off
about 5 minutes after the last key operation.
2.SPECIFICATIONS
Display 4 digits, 10 mm LCD, with blue backlight
Parameters: Ra, Rz
Display Range
Ra: 0.05-10.00um/1.000-400.0uinch
Rz: 0.020-100.0um/0.780-4000uinch
Accuracy: Not more than 10%
Fluctuation of display value: Not more than 6%
Sensor :
Test Principle: Inductance type
Radius of Probe Pin: 10um
Material of Probe Pin: Diamond
Measurement Force of Probe: 16mN(1.6gf)
Probe Angle: 90°
Vertical Radius of Guiding Head: 48mm
Maximum driving stroke: 17.5mm/0.7inch
Cutoff length (l): 0.25mm / 0.8mm / 2.5mm optional
Evaluation length: 1~5 cut off optional
Driving speed:
sampling length = 0.25mm Vt=0.135mm/s
sampling length = 0.8mm Vt=0.5mm/s
sampling length = 2.5mm Vt=1mm/s
returning Vt=1mm/s
Resolution : 0.001μm if reading 10μm
0.01μm if 10μm≤reading100μm
0.1μm if reading ≥100μm
Power Li-ion battery: rechargeable
Operating conditions: Temp. 0-50
Humidity <80%
Size140x57x48 mm (5.5x2.2x1.9 inch)
Weight: about 420 g
Attachment:
Weight: about 420 g
Attachment:
