MCLW11 Mechanical Three Roller Plate Bending/rolling Machine Export Indonesia

FOB Price

US$ 5000 - 100000 / Set

1 Set(Min. Order)

Port SHANGHAI
Payment TermsT/T Cash
Delivery Detail60 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Mertal	Place of Origin	China
Model Number	11NC-30X4000	Certification	ISO9001 CE
After-sales Service Provided	Engineers available to service machinery overseas	Warranty	12 months
Weight	20tons	Dimension(LWH)	640023503200
Condition	New	Voltage	380V
Power(W)	37KW

Product Description

Mechanical Three Roller Symmetrical Bending Machine

Mechanical Three Roller Symmetrical Bending Machine Features: The machine structure type symmetric three roller, roller in two central symmetrical position under the roller moves vertically through the screw nut worm drive and get the two lower rollers rotational movement, through the output gear reducer with lower tooth engagement provide torque roll sheet. the machine is compact structure, easy operation and maintenance. the machine requires the use of other equipment to complete pre-bending.

MCLW11 Mechanical 3-roller plate rolling machine technical parameters
Model	Max bending thickness(mm)	Max plate width(mm)	Diameter of upper roller(mm)	Main motor power(kw)
MCLW11-4x1500	4	1500	150	3
MCLW11-6x1500	6	1500	160	4
MCLW11-6x2000	6	2000	170	5.5
MCLW11-6x3200	6	3200	220	7.5
MCLW11-8x2000	8	2000	185	5.5
MCLW11-8x2500	8	2500	240	7.5
MCLW11-12x2000	12	2000	240	7.5
MCLW11-12x2500	12	2500	260	7.5
MCLW11-12x3000	12	3000	280	11
MCLW11-16x2000	16	2000	260	7.5
MCLW11-16x2500	16	2500	280	11
MCLW11-16x3200	16	3200	340	15
MCLW11-20x2000	20	2000	280	15
MCLW11-20x2500	20	2500	340	15
MCLW11-25x2000	25	2000	330	15
MCLW11-25x2500	25	2500	370	22
MCLW11-30x2500	30	2500	390	30
MCLW11-30x3000	30	3000	450	37
