Promotional CNC Machine Plate Rolls Ce Approved CNC Plate Rolling Machine Mclw12xnc-3*1000
Hydraulic CNC Four roller plate rolling machine
Superiority and some features usually only in large size plate rolling machine:
fully hydraulic-driven (as opposed to the usual manual and mechanical movement)
multiple independent hydraulic motor (as opposed to only one set of electric motors, reduction unit and gear)
automatic hydraulic line speed compensation (as distinct from inefficient clutch)
clamping pressure control (as opposed to holding without control)
Following users apply to use the machine
first use of the user, because this is one of the most easy-to-operate machine
operators lack of inspection requires high productivity,
increase profitability requires high accuracy,
improving quality want only one operator, reducing labor costs
due to the large size of the Board, production of high-or for security reasons require handling device
want to use CNC operations, reduce operational personnel action levels think factor
| MCLW12HXNC Four roller plate rolling machine technical parameters | |||||
| Model | Max pre-bending thickness(mm) | Max bending thickness(mm) | Diameter of upper roller(mm) | Max plate width(mm) | Main motor power(kw) |
| MCLW12-3x1500 | 2 | 3 | 135 | 1500 | 2.2 |
| MCLW12-5x1500 | 3 | 5 | 190 | 1500 | 4 |
| MCLW12-10x2000 | 8 | 10 | 240 | 2000 | 11 |
| MCLW12-10x2500 | 8 | 10 | 260 | 2500 | 15 |
| MCLW12-12x2000 | 10 | 12 | 260 | 2000 | 15 |
| MCLW12-15x2000 | 12 | 15 | 265 | 2000 | 18.5 |
| MCLW12-15x2500 | 12 | 15 | 280 | 2500 | 22 |
| MCLW12-20x2000 | 16 | 20 | 300 | 2000 | 30 |
| MCLW12-20x2500 | 16 | 20 | 340 | 2500 | 30 |
| MCLW12-25x2500 | 20 | 25 | 390 | 2500 | 30+7.5 |
| MCLW12-25x3000 | 20 | 25 | 420 | 3000 | 37+7.5 |
| MCLW12-30x2500 | 25 | 30 | 420 | 2500 | 37+7.5 |
| MCLW12-30x3000 | 25 | 30 | 460 | 3000 | 45 |
| MCLW12-35x2500 | 30 | 35 | 460 | 2500 | 45 |
| MCLW12-35x3000 | 30 | 35 | 510 | 3000 | 55 |
| MCLW12-35x3500 | 30 | 35 | 550 | 3500 | 55 |
| MCLW12-40x2500 | 35 | 40 | 510 | 2500 | 55 |
| MCLW12-40x3000 | 35 | 40 | 550 | 3000 | 55 |
| MCLW12-40x3500 | 35 | 40 | 560 | 3500 | 55+7.5 |
| MCLW12-50x2500 | 45 | 50 | 560 | 2500 | 55+7.5 |
| MCLW12-50x3000 | 45 | 50 | 605 | 3000 | 55 |
| MCLW12-50x3500 | 45 | 50 | 640 | 3500 | 75 |
| MCLW12-60x3000 | 50 | 60 | 670 | 3000 | 108.5 |
| MCLW12-60x3500 | 50 | 60 | 700 | 3500 | 75 |
| MCLW12-70x3000 | 65 | 70 | 720 | 3000 | 90 |
| MCLW12-70x3500 | 65 | 70 | 760 | 3500 | 90 |
| MCLW12-80x3000 | 70 | 80 | 780 | 3000 | 90 |
| MCLW12-80x3500 | 70 | 80 | 840 | 3500 | 55*2 |
| MCLW12-80x4000 | 70 | 80 | 870 | 4000 | 55*2 |
| MCLW12-90x3000 | 80 | 90 | 810 | 3000 | 75*2 |
| MCLW12-90x3500 | 80 | 90 | 890 | 3500 | 75*2 |
| MCLW12-90x4000 | 80 | 90 | 925 | 4000 | 75*2 |
| MCLW12-100x3000 | 85 | 100 | 850 | 3000 | 45*4 |
| MCLW12-100x3500 | 85 | 100 | 925 | 3500 | 45*4 |
| MCLW12-100x4000 | 85 | 100 | 960 | 4000 | 45*4 |
| MCLW12-120x3000 | 100 | 120 | 940 | 3000 | 55*4 |
| MCLW12-120x3500 | 100 | 120 | 980 | 3500 | 55*4 |
| MCLW12-120x4000 | 100 | 120 | 1020 | 4000 | 55*4 |
| MCLW12-140x3000 | 115 | 140 | 1000 | 3000 | 75*4 |
| MCLW12-160x3500 | 130 | 160 | 1220 | 3500 | 90*4 |
| MCLW12-180x3000 | 150 | 180 | 1280 | 3500 | 55*8 |
| MCLW12-200x4000 | 160 | 200 | 1500 | 4000 | 75*8 |
