Specifications
pu sandwich panel production linentinuous pu sandwich production line
2.free installation, and free technical guidance.
Continuous PU sandwich panel production line
The pu sandwich panel production line includers
1.embossing machine unit.
2.decoiling installations.
1 set of aluminum foil pre-heating installation
1 low-pressure PU or PF foaming machine
1 moble injector
1 set of paper-posting installation
1 conveyor laminator
1 set of hot-air circulation installation
1 dege-trimmer
1 automatic-tracking cutter and roller converyor
Usage
pu sandwich panel production line can produce phenolic/pu sandwich panel / phenolic /polyurethane foam insulation board.
Main technical parameters
| linear speed of production | 2-5 m/min |
| panel thickness | 10-100 mm |
| agitating speed | 4500 r/min |
| reciprocating time of injection head per minute | <1200 mm/s |
| maximum temperature of hot air circulating | 70 °C |
| laminating length of laminator | 24m |
| maximum clearance between conveyors | 300mm |
| total power | 198KVA |
| overall external dimensions | 47000*5365*3636 |
| external dimensions of embossing machine | 7050*3200*1600 |
| weight | 40tons |
Our Services
1.provide the company independent development and production of high quality phenolic/pu chemical raw materials.
2.provde production phenolic/polyurethane insulation board processing formula, and free to enjoy huahai phenolic institute proprietary technology upgrade services.
3.provide one-stop training, the client can send staff to my company production workshop learning phenolic/polyurethane insulation board processing technology.
4.provide one-set training, the company can send engineers to customer site interpretation training personnel.
5.maintenance engineer skills training, security production.
If you want to know more about our pu sandwich panel production line, please contact us.
Iris Wang
skype: Irislvmengze
mobile phone: 86+15263023710
We also use our pu sandwich panel production line produces pu sandwich panel.
