750W JET water pump
1 .Working conditions:
Max temperature of fluid up to: 50°C
Max ambient temperature up to: 40°C
Max Pressure: 8bar
2. Structural characteristics:
Pump casing: Cast Iron
Impeller: ABS/Brass/Noryl
Diffuser: Noryl/PPO/ABS/Cast iron
Motor Housing: Aluminum
Pump-motor adaptor: Aluminum/Cast iron
Mechanical seal: Stainless steel(graphite to ceramic)
Shaft: 45# steel or stainless steel
Bearing: SKF/NTN/NSK/China
Insulation class: B and F
Protection class: IP44 and IP54
3. Technical data (220V,50HZ)
Model | Power | Q.MAX (L/min) | H.MAX (m) | S.Head (m) | Speed (r.p.m) | Pipe Dia (Inch) | N.W (kg) | Packing size (mm) | |
W | HP | ||||||||
JET-60S | 460 | 0.6 | 45 | 35 |
9 |
2850 |
1″* 1″ | 12.8 |
375*188*200 |
JET-80S | 600 | 0.8 | 50 | 40 | 13.5 | ||||
JET-100S | 750 | 1 | 50 | 45 | 14.2 | ||||
Model | Power | Q.MAX (L/min) | H.MAX (m) | S.Head (m) | Speed (r.p.m) | Pipe Dia (Inch) | N.W (kg) | Packing size (mm) | |
W | HP | ||||||||
JET-60L | 460 | 0.6 | 55 | 35 |
9 |
2850 |
1″* 1″ | 15.3 |
435*188*200 |
JET-80L | 600 | 0.8 | 60 | 40 | 16.0 | ||||
JET-100L | 750 | 1 | 60 | 45 | 16.7 | ||||
110V,115V,127V,230V,240V,110/220V,50HZ/60HZ,380V 50HZ three-phase etc.Models are acceptable if request.
