Anti-corrosion Vacuum Pump Sets (Vacuum Pump & Booster Pump)
Application:
Series NKVW vacuum pumping system is composed of vacuum pump and roots pump, The roots pump automatically works by the controlling of relays or electrical-contact vacuum gauge.
NKVW equips an electrical control system and a cooling water system. It is quick start, big capacity of vacuum evacuating etc, widely used in vacuum smelting, welding, chemical, pharmaceutical and electric power system, particularly suitable for transformer vacuum operation.
Technical parameters:
Index |
NKVW-30 |
NKVW-70 |
NKVW-150 |
NKVW-300 |
Speed (L/S) |
30 |
70 |
150 |
300 |
Ultimate pressure (Pa) |
7 |
|||
Working vacuum (Pa) |
133 |
|||
Power (kW) |
1.85 |
3.7 |
7 |
9.5 |
Power supply |
380V 3Ph 50Hz (As per user’s option) |
|||
Weight (kg) |
240 |
400 |
580 |
1000 |
Dimension (mm) |
700*500*1200 |
880*600*1300 |
1000*700*1500 |
1350*720*1600 |
NAKIN Company products list as following:
ZY-high effective vacuum transformer oil purifier, oil filtration
ZYD-Double stages insulating oil purifier, oil treatment, oil purification
ZYM-Mobile/trailer type transformer oil treatment, oil filtration machine
AD-Air dryer for drying electric equipments
TY-Turbine oil purifier, oil treatment
TJ-Coalescence and separating oil filter, oil purifier machine
TYA-Lubricating oil purifier/hydraulic oil purification
TYK- Phosphate ester fire-resistant oil purifier, oil filtration machine
JZS-Engine oil regeneration system, waste oil recycling
BZ-Transformer oil regeneration device, oil purifier
PF-Plate pressure oil filter, oil purifier machine
JL-Portable oil purifier, oil filtering, oil filter
IIJ-II-BDV oil tester, insulating oil dielectric strength tester
NKEE-Oil moisture sensor, water content sensor
