Specifications
NK Highly Vacuum Pump Machine:1.big capacity of vacuum evacuating
2.equips an electrical control system
NK Highly Vacuum Pump Machine
Application:
NK Highly Vacuum Pump Machine is composed of vacuum pump and Roots pump, widely used in vacuum smelting, welding, chemical, pharmaceutical and electric power system, particularly suitable for transformer vacuum working.
Features:
1. NKVW is quick start, big capacity of vacuum evacuating.
2. Roots pump automatically works by the controlling of relays or electrical-contact vacuum gauge.
3. NKVW equips an electrical control system and a cooling water system.
4. The vacuum pump can be Germany LEYBOLD, also the China brand vacuum pump.
Technical parameters:
Index |
NKVW-30 |
NKVW-70 |
NKVW-150 |
NKVW-300 |
Speed (L/S) |
30 |
70 |
150 |
300 |
Ultimate vacuum (Pa) |
7 |
|||
Working vacuum (Pa) |
133 |
|||
Power (kW) |
1.85 |
3.7 |
7 |
9.5 |
Power supply |
380V 3Ph 50Hz (As per user’s option) |
|||
Weight (kg) |
240 |
400 |
580 |
1000 |
Dimension (mm) |
700*500*1200 |
880*600*1300 |
1000*700*1500 |
1350*720*1600 |
