Dielectric Oil Breakdown Voltage Tester
Application:
IIJ-II oil tester is the most advanced and complete design for repeatable, accurate measurement of breakdown voltage of insulating oils used in electrical equipment, the testing cells is made according to standard IEC156.Including preprogrammed test sequences, internal momory, built-in printer, LCD displayer. The oil tester can be used for both field and laboratory.
Technical Parameters:
Power supply |
AC220V±10%,50Hz |
Output voltage |
0~100KV(60KV,80KV,100KV) |
Capacity |
1.2KVA(1.6KVA, 2.0KVA) |
Speed of pressure rise |
about 2KV/S |
Voltage test precision |
±1% |
Breakdown sensitivity |
<2KV |
Wave difference |
≤3% |
Time of breakdown |
≤10ms |
Working condition-temperature |
0°C~40°C |
-humidity |
The biggest comparatively humidity85% |
Reserve circumstance-temperature |
-20°C~60°C |
-humidity |
The biggest comparatively humidity75% |
- Working altitude |
<1500m (if over 1500m can be designed specially) |
Dimension |
480mm*460mm*460mm |
Our Main Series Products as following:
ZY-Single stage vacuum transformer oil purifier/oil filtration machine
ZYD-Double stages vacuum Transformer oil purifier/oil filtration machine
ZYM-Mobile type transformer oil purifier/oil filtration machine
AD-Air drying machine
TY-Vacuum Turbine oil purifier/oil filtration machine
TJ-Coalescence–Separating oil purifier/oil filtration machine
TYA-Vacuum Lubricating oil purifier/oil filtration machine
CXJ-Centrifugal oily water separating machine
JZS-Waste Engine oil regeneration machine
ZYS-On-load Tap Changer Oil Purifier
BZ-Transformer oil regeneration device
PF-Press paper oil filtration machine
JL-Portable oil oil purifier/oil filtration unit
BDV Dielectric oil’s breakdown voltage tester
NKEE-Transformer oil/lube oil moisture sensor
Oil purifier parts and various oil testing equipments (Oil Acid tester, oil viscosity tester)
Our Honor and Quality Certificate:
China Famous brand Oil Purifier Company
Golden-supplier for China National Electric power Group
Golden-Supplier for ALSTOM, SIEMENS, SCHNEIDER Company
ISO9001 products quality certificate
CE Products safety certificate
SGS Products local testing report
More than 10 years and 50 countries and districts exporting experience
Our After-sales:
Engineer is available for local installation.
24 months warranty from the delivery time.
24 hours online service question and answer.
More than 10 years experience
Packing and delivery way:
Wooden case Suitable for sea transportation and air transportation
