| Features: |
|
1. Radiating capacity: 50W / °C; |
|
SPECIFICATIONS
|
|
One-stop automatic intelligent temperature control: in different environment, user does not need to change setting due to it will automatically switch to appropriate operating temperature. |
CW-5000BG applied to cool a single 120W CO2 laser tube (emitting rate higher than 60%);
CW-5000 TECHNINICAL PARAMETERS
Model |
CW- 5000AG |
CW-5000BG |
CW-5000DG |
CW-5000AK |
CW-5000BK |
CW- 5000DK |
||
Voltages |
AC220~240V |
AC208~230V |
AC100~110V |
AC220~240V |
AC208~230V |
AC100~110V |
||
Frequency |
50Hz |
60Hz |
50/60Hz |
50Hz |
60Hz |
50/60Hz |
||
Current |
1.4~2.1A |
3.5~5.6A |
1.4~2.1A |
3.5~5.6A |
||||
Capacity |
6L |
|||||||
Inlet and outlet hold |
Outside dimensions 10mm brass connector
|
Inside dimensions 8mm speedy connector |
||||||
Max pumping lift |
10M |
100M |
||||||
N.W |
26Kg |
29Kg |
||||||
G.W |
31Kg |
34Kg |
||||||
Dimensions(L*H*W) |
55*28*43cm |
|||||||
Paching dimensions(L*H*W) |
71*41*62 cm
|
|||||||
|
Chiller working theory:
Compressor: suck the steam of refrigerant in the evaporator, compress it to the condensation pressure, then row into condenser,
Condenser: condense the high pressured refrigerant steam from compressor to liquid, during the condense process, refrigerant steam give out hot, so it needs water or air to cool.
throttling set: refrigerant liquid flow through throttling set, the pressure will fall from condense level to evaporating pressure. Part of the liquid transformed to steam
Evaporator: steam the refrigerant ,to withdraw the target temperature, evaporator give off cold , it can chill the liquid or air.
|
We supply all laser parts for co2 laser cutting & engraving machine, your kindly inquiry will be much appreciated !
1. co2 laser tube 20w 30w 40w 50w 60w 70w 80w 100w 120w 130w 150w economical model
2. economical power supply for economical laser tube
3. RECI co2 laser tube Z2 Z4 Z6 Z8 4. EFR co2 laser tube F series and Zn series
5. power supply for reci laser tube dy10 dy13 dy206. All dimension silicon mirror and ZnSe(USA) lens
7. High quality co2 laser controller leetrompc6525 awc608 awc608c rdlc 320
8. Water chiller for laser tube
9. optical and mechanical parts whole sets for engraving machine (single head or double head )
10. mechanical parts whole sets for engraving machine (out slider, inner slider and linar Square slider )
