Specifications
high speed double head dsp motion controller usb port cad coredraw photoshop software preview outside slider rails more stable1610 express double head co2 laser cutting machine
Parameter:
Model: | 1610 (Double Laser Head) |
Working Area: | 1600x1000(mm) |
Laser Power: | 80W, 100W |
Laser Type: | Sealed CO2 laser tube |
Working Platform: | Honeycomb/Blade |
Working Speed: | ≤700mm/s |
Positioning Accuracy: | ±0.05mm(Red Dot) |
Graphic Format Supported: | BMP PLT DST AI DXF etc. |
Cooling System: | Water cooling and protecting system |
Working Voltage: | AC220V±10% ,50~60Hz , 10A max |
Working Temperature: | 0~45℃ |
Operating Humidity: | 5%~95% |
Motor: | Stepping (Servo Optional) |
Whole Machine Size: | 2220x1570x1035(mm) |
Optional: | Double Head Switch |
features
1) Quick Curve Cutting: Cut any curve fast and Continuous cutting. The movement
of laser head is graceful like a moving top Gear .
2) Full supported for CAD, CORELDRAW, PHOTOSHOP and other sofeware ,
USB interface is friendly to use , meet the demand of the market .
3) Multi-Document Function: This series can restore up to 256 job files, Operator can
choose the job file on the laser machine independently without computers, then
realize the producing of 256 different products.
4) All optical isolation system and High speed differential input/output circuit
can avoid distortion when transmitting for a long distance, strong ability of anti-interference. The system has realized 12-way work status output and 16-way input to meet the manufacturing spot of our client
5) Large format laser cutting machine cut smooth fine ,can meet the fabric
,cloth punching and cutting .
6) Stable optical system ,with industrial chiller ensure large format cutting
.laser power output is stable,fast and efficient.
7) working table area can be customized according to users'need.
Application Industry:
Garment, Shoes, Textile, Embroidery, Leather, Bag and cases, Outdoor,
Sports, Car seat fabric etc.
Application Material:
Leather, artificial leather, Soft Leather, Decoration Leather, Packing Leather,
etc. Cotton, Silk, Chemical Fiber, Jeans, etc.
Typical Applications:
Material Cutting for Garment, Shoes, cloth toy, Cases and Handbags,
Camping Equipment, Car Seats fabric , Hollowed -out Tablecloth, Lable cutting
1610 express double head co2 laser cutting machine
