Specifications
Strength Testing Rotary Drum:It is suitable for testing the mechanical strength of sinters and pellets used in blast furnace
GM/SZ-98 Strength Testing Rotary Drum of Sinters and Pellets
Typical Application:
In accordance with GB8209-87, the method of testing impact resistance index and abrasion resistance index of sinters and pellets, it is suitable for testing the mechanical strength of sinters and pellets used in blast furnace under the normal temperature.
The material will be discharged to the drum screen directly for automatic sieving, this drum is environment-friendly, it is full-sealed and equipped with dusting interface, the worker can push the drum screen into drum for sieving, which improves the operating environment and condition greatly and also can decrease labor intensity, it is one of necessary equipments for sinter or metal factory.
Technical Parameter:
GM/SZ-98 Strength Testing Rotary Drum of Sinters and Pellets | |||
Size of inside drum |
1000*500mm |
Liftout plate |
2pcs |
Thickness of drum |
5mm |
Weight of material |
15KG |
Particle size of material |
10-40mm |
Motor power |
2.2KW |
Rotating speed |
25+1 r/min, 200r/8mins |
Total weight |
1000KG |
Power supply |
380V |
Dimension |
1800*1500*2200mm |
Remark |
Drum screen of 500×800mm, hole size of 6.3×6.3mm is available. |
||
