CDM-15M Multi-function Concrete Core Drilling Machine for Sale

Name: CDM-15M Multi-function Concrete Core Drilling Machine for Sale
Brand: GEOTEST EQUIPMENTS
SKU: 143207308
Availability: InStock

Shaoxing GeoTest Equipment Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

GEOTEST EQUIPMENTS

Model Number:

CDM-15M

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo Shanghai Negotiable

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name GEOTEST EQUIPMENTS

Model Number CDM-15M

CDM-15M Multi-function Concrete Core Drilling Machine for sale

Charateristics:

a. Suitable to cut/drill cores of concrete, rocks, stones, tiles or the similar materials.

b. The machine is suitable for core samples of size upto 200mm diameter.

c. The machine has sturdy base with pillar support in which rack and pinion is provided for adjustment in height and penetration assembly.

d. A suitable diesel engine is fitted in the machine with cooling arrangement with water.

e. It has multi-function such as core drilling, cutting and drilling the concrete samples.

Model	CDM-15M
Max.diameter of core drilling samples	150 mm
re drilling depth	400 mm
Core drilling direction	Vertical down
Input method	Hand operated
Rotation speed of main shaft	500-1000 r.p.m
Core bits	Diamond thin-wall core bits
Cutting(grinding)direction	Horizontal
Max cutting (grinding) diameter	150 mm
Max cutting (grinding) height	150 mm
Cutting saw and grinding head	Diamond
Power	Single-phase series motor 2.5KW
Power supply	220V
Overall dimensions	470x280x880mm
Weight approx	45kg
