CDM-20M Concrete Drilling Machine (muti-function)

Name: CDM-20M Concrete Drilling Machine (muti-function)
Brand: GEOTEST EQUIPMENTS
SKU: 143207312
Availability: InStock

Shaoxing GeoTest Equipment Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

GEOTEST EQUIPMENTS

Model Number:

CDM-20M

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo Shanghai Negotiable

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name GEOTEST EQUIPMENTS

Model Number CDM-20M

CDM-20M Concrete Drilling Machine (muti-function)

Charateristics:

a. Suitable to cut/drill cores of concrete, rocks, stones, tiles or the similar materials.

b. The machine is suitable for core samples of size upto 200mm diameter.

c. The machine has sturdy base with pillar support in which rack and pinion is provided for adjustment in height and penetration assembly.

d. A suitable diesel engine is fitted in the machine with cooling arrangement with water.

e. It has multi-function such as core drilling, cutting and drilling the concrete samples.

Model	CDM-20M
Max.diameter of core drilling samples	200 mm
re drilling depth	400 mm
Rotation speed of main shaft	1100-1500 r.p.m
Power	13 HP, Honda Engine
Start mode	Electric
Overall dimensions	1060x870x1300mm
Weight approx	122kg
