Fiber Laser Marking Machine (F10W/ F20W)

Fiber Laser Marking Machine (F10W/ F20W) thumbnail-1
Fiber Laser Marking Machine (F10W/ F20W) photo-1
US$ 5,000 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Laser Type:
Fiber Laser
Engraving Area:
(standard ) 110*110mm (f=160mm)
Contact Supplier Request Quote Chat Now
China National Silk Imp. & Exp. Wuxi Corp., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Laser Type Fiber Laser
Engraving Area (standard ) 110*110mm (f=160mm)
Engraving Speed 0-7000mm/s
CNC or Not Yes
Cooling Mode Air Cooling
Applicable Material Acrylic, Crytal, Glass, Leather, MDF, Metal, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood, Other
Graphic Format Supported AI, PLT, DXF, BMP, DST, DWG, LAS, DXP, Other
Brand Name XINGUANG
Model Number XG
Certification CE, ISO
After-sales Service Provided Overseas third-party support available

Specifications

Model NO.:
F10W/ F20W
Type:
Laser Engraving Machine

Basic Info.

Export Markets: Global

Product Description

The XINGUANG CO-Series Laser Markers, available in three different power levels, the 10W ModelCO10, the 20W model CO20, the 30W Model CO30 and the 50W model CO50.CO2 laser marker use.Adopt Import RF excited CO2 tube assures a long time life cycle and maintenance free operation.CO30 and CO50, also best choice for "marking on the -fly", suiable for nonmetal materials such as leather, cloth, wood, bamboo, paper, organic materials, plastic, epoxy resin etc.
CO2 laser marker composed by: Laser system:CO2 module, civity mirrors, beam expander, Scanner, air cooling ^etc Control system:PC, PCI card, marking software Frame and table
Product highlights 30, 000 hours + of laser lifetime before recharging Mount in any orientation Air-cooled design (no water or external chiller required) Zero maintenance Low cost of ownership
Laser marking process The physical principle of laser marking is based on Light amplifaction by simulated emission of radiation. In other words, The energy to excite the crystal Is created by a CO2 and collected and Concentrated between two reflecting mirrors Mounted on the galvanometers.They deflect The beam to produce marking on the part
Laser software 1 Users can design their graphics freely. 2 Various types of fonts are supported. Such as TrueType, JSF(Single line font ), DMF(DOT Matrix Font, One-Dimensional bar code, Two-Dimensional bar code, and so on 3 Flexible variable text:Changes the text real Time while in laser processing.Excel datasheet Is supported. 4 Strong node editing function make the curve Modification more easier 5 The software can support 265 "pencils", Which used to draw graphic and can be set Different processing parameters. 6 Common types of images are supported. (BMP, JPG, GIF, tga, PNG, TIF^) 7 Common vector images are supported.(ai, dxf, dst, plt^) 8 Image processing (Grayscale, White / Black Transformations) 9Powerful hatching functions, such as support round hatch
Application Application material:Majority of nonmetal materials such as leather, cloth, wood, bamboo, paper, organic materials, plastic, epoxy resin etc. Application Industry:Electronic components, medicines, food, drinking package, leather products, rag trade, woodworks, craftworks and package.

MACHINE MODEL CO10 CO20 CO30 CO50
Laser power 10W 20W 30W 50W
Laser module Made in CHINA Made in USA
Laser wavelength 10.6um 10.6um 10.6um 10.6um
CO2 module using life 30, 000 hours
Marking scope (standard ) 110*110mm (f=160mm) optional: 145*145mm (f= 210MM ) 175*175mm (f= 254mm)
Marking speed 0-7000mm/s
Marking deepth 0-50mm
Minimum character 0.4mm 0.4mm 0.4mm 0.4mm
Power supply AC 220V/50HZ
Power consumption 500w 800W 1000w 1500w
Cooling mode Air
