12V20Ah LiFePO4 Battery for Replacing Lead Acid Battery

Name: 12V20Ah LiFePO4 Battery for Replacing Lead Acid Battery
Brand: O'CELL
SKU: 143102468
Availability: InStock

Negotiable MOQ: 20 Packs (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

O'CELL

Model Number:

IFM12-200E3

Ocell New Energy Technology Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name O'CELL

Model Number IFM12-200E3

Type Li-Ion

Components Other, LiFePO4

Size L181*W76*H166mm

Voltage 12.8V

Weight 2.75Kg (6.0 lbs)

Nominal Capacity 20Ah

Application golf cart

Specifications

Steady power output;
Longer service life;
No acid leak;
Lightweight;

Features

1. Read the charge/discharge times which is useful for quality dispute

2. Re-adjust the major parameters according to different application

3. Read voltage, current of the cells in series

4. Read other information such as SOC, Temperature etc.

5. Know residual capacity simply by LED indicator

6. Half weight of standard 12V17Ah SLA battery

Specification

1	Rated Capacity	20.0Ah	Standard discharge(0.5C)after standard charge(0.5C)
2	Minimal Capacity	19.2Ah	Standard discharge(0.5C)after standard charge(0.5C)
3	Nominal Voltage	12.8V
4	Cycle Life	Higher than 60% of the Initial Capacity of the battery pack	1)Charge: 0.5C CC to 14.6V, then CV till current to 0.05C 2)Rest: 30min. 3)Discharge: 0.5C to 10.0V 4)Carry out 1200cycles (Temperature:20±5°C)
5	Discharge cut-off voltage	≥ 9.2V(2.3V/cell)	10.0V(recommended)
6	Charging cut-off voltage	≤ 15.6V(3.9V/cell)	14.6V(recommended)
7	Cell and assembly method	IFR26650EC-3.3AH	4S6P
8	Packing material	ABS
9	Standard charge	0.5C constant current(CC) charge to 14.6V,then constant voltage (CC)14.6V charge till charge current decline to ≤0.05C	Charge time : Approx 3.5h
10	Standard discharge	Constant current 0.5C to 10.0V
11	Maximum Charge Current	18A	10A or less recommended for better peformance and longer life
12	Continuous Discharge Current	18A	Over current 20±2A (900ms~2000ms)
13	Operation Temperature Range	Charge: 0~45°C	60±25%R.H.
13	Operation Temperature Range	Discharge: -10~50°C	60±25%R.H.
14	Storage Temperature Range	Less than 1 year : 0~25°C	60±25%R.H. at the shipment state
14	Storage Temperature Range	Less than 3 months:-5~35°C	60±25%R.H. at the shipment state
15	Approx Weight	2.75Kg
16	Maximum Dimension	L181W76H166mm	Standard 12V17Ah SLA dimension
