Lifepo4 12V 20ah Golf Cart Battery Lithium Golf Trolley Battery

Name: Lifepo4 12V 20ah Golf Cart Battery Lithium Golf Trolley Battery
Brand: ocell
SKU: 143102472
Availability: InStock

US$ 150 - 220 MOQ: 10 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

ocell

Model Number:

12 20

Ocell New Energy Technology Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name ocell

Model Number 12 20

Type Li-Ion

Size 181*76*166mm

Voltage 12V, 12V

Weight 2.75kg

Nominal Capacity 20ah

Application Golf cart

Specifications

1.12v 20ah golf cart battery
2. golf trolley battery
3. lithium golf caddy battery
4.One year warranty

Lifepo4 12V 20ah golf cart battery lithium golf trolley battery

Features

1. Read the charge/discharge times which is useful for quality dispute

2. Re-adjust the major parameters according to different application

3. Read voltage, current of the cells in series

4. Read other information such as SOC, Temperature etc.

5. Know residual capacity simply by LED indicator

6. Half weight of standard 12V17Ah SLA battery

Specification

1	Rated Capacity	20.0Ah	Standard discharge(0.5C)after standard charge(0.5C)
2	Minimal Capacity	19.2Ah
3	Nominal Voltage	12.8V
4	Cycle Life	Higher than 60% of the Initial Capacity of the battery pack	1)Charge: 0.5C CC to 14.6V, then CV till current to 0.05C 2)Rest: 30min. 3)Discharge: 0.5C to 10.0V 4)Carry out 1200cycles (Temperature:20±5°C)
5	Discharge cut-off voltage	9.2V	10.0V(recommended)
6	Charging cut-off voltage	15.6V	14.6V(recommended)
7	Cell and assembly method	IFR26650EC-3.3AH	4S6P
8	Packing material	ABS
9	Standard charge	0.5C constant current(CC) charge to 14.6V,then constant voltage (CC)14.6V charge till charge current decline to ≤0.05C	Charge time : Approx 3.5h
10	Standard discharge	Constant current 0.5C to 10.0V
11	Maximum Charge Current	18A	18A recommended for better peformance and longer life
12	Continuous Discharge Current	18A	Over current 20±2A (900ms~2000ms)
13	Operation Temperature Range	Charge: 0~45°C	60±25%R.H.
13	Operation Temperature Range	Discharge: -10~50°C	60±25%R.H.
14	Storage Temperature Range	Less than 1 year : 0~25°C	60±25%R.H. at the shipment state
14	Storage Temperature Range	Less than 3 months:-5~35°C	60±25%R.H. at the shipment state
15	Approx Weight	2.75Kg
16	Maximum Dimension	L181W76H166mm	Standard 12V17Ah SLA dimension
