12V13Ah LiFePO4 Battery

Name: 12V13Ah LiFePO4 Battery
Brand: O'CELL
SKU: 143102470
Availability: InStock

Negotiable MOQ: 20 Packs (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

O'CELL

Model Number:

IFM12-130E2

Ocell New Energy Technology Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name O'CELL

Model Number IFM12-130E2

Specifications

UL approved LiFePO4 cells;Qualified built-in BMS

Specification

1	Rated Capacity	13.2Ah	Standard discharge(0.5C)after standard charge(0.5C)
2	Minimal Capacity	12.8Ah
3	Nominal Voltage	12.8V
4	Cycle Life	Higher than 60% of the Initial Capacity of the battery pack	1)Charge: 0.5C CC to 14.6V, then CV till current to 0.05C 2)Rest: 30min. 3)Discharge: 0.5C to 10.0V 4)Carry out 1200cycles (Temperature:20±5°C)
5	Discharge cut-off voltage	9.2V	10.0V(recommended)
6	Charging cut-off voltage	15.6V	14.6V(recommended)
7	Cell and assembly method	IFR26650EC-3.3AH	4S4P
8	Packing material	PVC
9	Standard charge	0.5C constant current(CC) charge to 14.6V,then constant voltage (CV)14.6V charge till charge current decline to ≤0.05C	Charge time : Approx 3.5h
10	Standard discharge	Constant current 0.5C to 10.0V
11	Maximum Charge Current	20A	6.5A or less recommended for better peformance and longer life
12	Maximum Continuous Discharge Current	20A	Over current 60±10A (10ms~20ms)
13	Operation Temperature Range	Charge: 0~45°C	60±25%R.H.
13	Operation Temperature Range	Discharge: -10~50°C	60±25%R.H.
14	Storage Temperature Range	Less than 1 year : 0~25°C	60±25%R.H. at the shipment state
14	Storage Temperature Range	Less than 3 months:-5~35°C	60±25%R.H. at the shipment state
15	Approx Weight	1.5Kg
16	Maximum Dimension	L220W68H55mm
