Specifications
37 screw air compressor features:a.High Stability,b.Better reliability,c.Lower Noise,d.More saving energy
Packaging & Delivery
| Packaging Details: | Plywood case or customized |
|---|---|
| Delivery Detail: | 20 days |
<:article id=richTextContainer>
Specifications
75kw screw air compressor for industry features: a. High Stability, b. Better reliability, c. Lower Noise d. More saving energy.
75kw screw air compressor for industry:
Air End
No vibration and low noise interpret perfectly the genuine made in Germany. Big rotor, low speed of rotation and direct connection.
Motor
First-class motors are adopted, with the level of protection being IP54 and insulation level being F.
Rotor
Rotors are asymmetric in profile, backed up by ball bearings and roller bearings. Operates at a low speed, thereby low in abrasion and maintenance expenses, air end is long service life. Helical gears can produce axial force to kill some acting force, which reduces the load of the bearing of air end.
Control panel
Intelligent microcomputer-based control technology can monitor and control in all aspects the complete machine following your instructions, remote control realizes unattended operation, and the user-friendly human-machine interface displays instructions and parameters in written form also, it can function to self diagnose faults, give warning and automatically regulate the capacity.
| Model | SMAC-30A | SMAC-37A/W | SMAC-45A/W | SMAC-55A/W | SMAC-75A/W |
| FAD/ Pressure (m3/min/Mpa) | 5.2/0.7 | 6.4/0.7 | 8.0/0.7 | 10.5/0.7 | 13.6/0.7 |
| 5.0/0.8 | 6.1/0.8 | 7.7/0.8 | 9.8/0.8 | 13.3/0.8 | |
| 4.3/1.0 | 5.7/1.0 | 7.0/1.0 | 8.7/1.0 | 11.6/1.0 | |
| 3.7/1.3 | 5.1/1.3 | 5.8/1.3 | 7.5/1.3 | 9.8/1.3 | |
| Power (KW) | 30 | 37 | 45 | 55 | 75 |
| Horse power (HP) | 40 | 50 | 60 | 75 | 100 |
| Voltage/Hz | 380V/3ph/50hz or customized | ||||
| Start mode | Y-delta start | ||||
| Noise DB (A) | 69±2 | 70±2 | 72±2 | 73±2 | 75±2 |
| Air pipe (Inch) | G1 1/4 | G1 1/2 | G11/2 | G2 | G2 |
| Ambient Temp.(°C) | -5°C~+45°C | ||||
| Weight (mm) | 680 | 840 | 860 | 1600 | 1750 |
| Length L (mm) | 1000 | 1300 | 1300 | 1500 | 1650 |
| Width W (mm) | 1100 | 1000 | 1000 | 1150 | 1350 |
| Height H (mm) | 1240 | 1460 | 1460 | 1500 | 1500 |
| Cooling Water Capacity (T/H) | / | / | 3 | 5 | 5 |
Package: Plywood case
Factory View:
