1hp Deep Well Water Pump 0.75kw

Trupow Industrial Stock Co., Ltd.
1hp Deep Well Water Pump 0.75kw thumbnail-1
1hp Deep Well Water Pump 0.75kw photo-1
US$ 76.35 - 77.45 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
TRUPOW
Model Number:
4SKm 100
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name TRUPOW
Model Number 4SKm 100
Theory Electromagnetic Pump
Structure Multistage Pump
Usage Water
Power Electric
Standard or Nonstandard Standard
Fuel Other, Electric
Pressure High Pressure
Application Submersible

1hp deep well water pump 0.75kw

Qmax: 3.5 ( m3/h )

Capacity from 1 to 2 ( m3/h )

Total head from 140 to 20 ( m )



Motor

Continuous service.

Power: 1 to 2 HP ( Single phase )

            1 to 2 HP ( Three phase )

Insulation class: B

Protection grade: IPX8

Maximum diameter: 93 mm

Highest temperature of liquid: 35oC



Main uses

For 4’’ wells.

Pumping clear water into: Detached house

-Country houses and farms- cottages.

Moving water in fountains.

Rain irrigation.

Feeding pressure systems.

Filling and emptying tanks.



Structure features

Shaft, jacket and hydraulics in stainless steel.

Brass impeller.

Built- in non- return valve.

Thermoplastic parts.

Oil-cooled motor with compensating diaphragm.

Graphite mechanical seal protected by sand proof ring.

4SKm series parts are non-toxic and non-polluting.



1hp deep well water pump 0.75kw



Type

Motor Power

Capacity and Head

Dimensions

Control

220-240V

/50Hz

380-415V

/50Hz

M3/h

0

0.5

1

1.5

2

2.5

L

W

Current max

kw

hp

L/min

0

8.3

16.6

24.9

33.2

41.5

mm

kg

A

4SKm100

4SK100

0.75

1



Head (m)

61

54

45

36

28

20

485

15.5

6

4SKm150

4SK150

1.1

1.5

99

83

68

54

38

22

552

16.5

10

4SKm200

4SK200

1.5

2

140

130

120

100

90

70

606

17.5

13



Workshop



Exhibition



Certification

You can believe&choose us :

-- 11 years experiences in supplying pumps to Europe, Australia, USA, Russia.

    professional design team to design anything all according to your requirements,such as the package,etc.

    experienced technology workers to guarantee the products quality.



-- strong quality control system:

    Raw material control / process control/component quality contorl/ finished product quality inspection/ mass production

    spot check/ company check



--  Best after-sale service, offer you 1 year warranty.

     you will be 100% satisfied with our products.



-- Not only produce deep-well submersible pumps  , but also we can offer garden pumps, pond products, etc.
