Specifications
*High performance*High-quality body with elegant appearance
*1-2 years warranty
*CE, GS ,EMC, RoHS
75QJD110-0.25 DEEP-WELL SUBMERSIBLE PUMP WATER PUMP FOR AGRICULTURE
submersible pump for agriculture
| n=2850r/min Outlet:G1”~1 1/4” |
| ||||||||||||||||
Flow (l/min) | ||||||||||||||||||
0 | 8 | 17 | 25 | 30 | 33 | 42 | 47 | |||||||||||
Flow (m³/h) | ||||||||||||||||||
0 | 0.5 | 1 | 1.5 | 1.8 | 2 | 2.5 | 2.8 | |||||||||||
Type | Motor power |
| Dimensions | |||||||||||||||
Single phase 220-240V~50Hz | Kw | Hp | Head (m) | Length mm | Weight mm | |||||||||||||
75QJD110-0.25 | 0.25 | 0.33 | 38 | 36 | 33 | 28 | 23 | 20 | 10 | 4 | 744.5 | 7.75 | ||||||
75QJD115-0.37 | 0.37 | 0.5 | 55 | 54 | 50 | 40 | 34 | 29 | 14 | 5 | 917 | 9.35 | ||||||
75QJD122-0.55 | 0.55 | 0.75 | 79 | 78 | 72 | 58 | 50 | 42 | 20 | 7 | 1148 | 11 | ||||||
75QJD130-0.75 | 0.75 | 1 | 108 | 105 | 93 | 76 | 64 | 57 | 27 | 10 | 1389 | 13.3 | ||||||
75QJD140-1.1 | 1.1 | 1.5 | 144 | 132 | 120 | 91 | 76 | 60 | 25 | 13 | 1699 | 15.7 | ||||||
COMPONENTS:
-Motor
-Pump
MATERIAL:
-External pump body: Stainless Steel
-Suction strainer: Stainless Steel
-Impeller: PPO/SS
-Bearing brackets: Brass
-Shaft: Stainless Steel
-Motor housing: Stainless Steel
-Mechanical seal: Special seal for deep well(carbon-SIC/TC)
FEATURE:
-Pump
Qmax: 7.8 m3/h
Capacity from 2 to 4 m3/h
Total head from 75 to13m
-Motor
Power: 0.55 to 1.5 kw
Insulation class: B
Protection grade: IP68
Maximum diameter: 126mm
APPLICATION:
-For water supply from wells or reservoirs.
-For domestic use, for civil and industrial application.
OPERATING LIMIT:
-Highest temperature of liquid:35°c
You can believe&choose us :
-- 9 years experiences in supplying pumps to Europe, Australia, USA, Russia.
professional design team to design anything all according to your requirements,such as the package,etc.
experienced technology workers to guarantee the products quality.
-- strong quality control system:
Raw material control / process control/component quality contorl/ finished product quality inspection/ mass production
spot check/ company check
-- Best after-sale service, offer you 1 year warranty.
you will be 100% satisfied with our products.
