self priming horizontal multistage pump
USD $90 - $95
/ Piece
100 Pieces(Min.Order)
- 50000 Piece / Pieces per Month
- NINGBO
- T/T
You May Like
-
MONO progressive block for prefabried concrete houses
-
MONO progressive block for concrete pump spare parts
-
MONO progressive block for ready mix concrete trucks
-
MONO progressive block for concrete statue molds
-
MONO progressive block for concrete columns mold
-
MONO progressive block for gearbox for concrete mixer
Product Details
| Place of Origin: | Zhejiang, China | Brand Name: | TRUPOW | Model Number: | HMC-SAU |
| Theory: | Jet Pump | Structure: | Multistage Pump | Usage: | Water |
| Power: | Electric | Standard or Nonstandard: | Standard | Fuel: | Other, Electric |
| Pressure: | High Pressure |
Product Description
Specifications
horizontal multistage pump1.Horizontal Self -priming pump
2.Continuous duty
Self priming Horizontal Multistage Pump Specifications:
Operating limits:
1.Liquid temperature up to 60ìC
2.Ambient temperature up to 40ìC
3.Total suction lift up to 9meters
4.Continuous duty
Motor:
1.Two-pole induction motor( n=2900rpm)
2.Insulation Class F
3.Protection IP44
4.Protected by thermal protector
Material:
1.Pump body: Cast iron
2.Impeller: stainless steel
3.Motor housing: Aluminium
4.Shaft: Stainless iron
5.Mechanical sealing: Graphite/Ceramic
6.Bearing: NSK original in Japan/Made in China
Application:
-Centrifugal vertical multistage water pumps able to develop high pressure and a high water lift with a comparatively low power consumption
-Universal pump for civil and industrial purposes,for high pressure system and for irrigation in agriculture and pool fittings.
MODEL | POWER | MAX HEAD (M) | MAX FLOW (L/h) | MAX SUC.DEPTH (M) | IMPELLERS (PC) | QTY/20”CTR (PC) | |
KW | HP | ||||||
HMC-4SAU | 0.75 | 1.0 | 45 | 6600 | 9 | 4 | 1900 |
HMC-5SAU | 0.90 | 1.2 | 55 | 7200 | 9 | 5 | 1800 |
