Multi-Stage Pump
US$ 42.5 - 60
/ Piece
200 Pieces(Min. Order)
- NINGBO
- T/T
You May Like
-
EGDa Series Submersible Screw Pumps
-
QGD Series Submersible Screw Pumps
-
EGD Series Submersible Screw Pumps
-
Top Quality 4'' 1.0HP Bore Water Stainless Steel Deep Well Submersible Pump
-
NEW 4'' 0.75HP DEEP WELL SUBMERSILE BORE WATER PUMP 4SDM2/8
-
4 INCH 1.5HP DEEP WELL SUBMERSILE BORE WATER PUMP 4SDM2/14
Product Details
| Place of Origin | Zhejiang, China | Brand Name | TRUPOW | |
| Model Number | HMC-SA | Theory | Jet Pump | |
| Structure | Multistage Pump | Usage | Water | |
| Power | Electric | Standard or Nonstandard | Standard | |
| Fuel | Other, Electric | Pressure | High Pressure |
Product Description
Specifications
Multi-Stage Pump1) Horizontal Self-priming pumps
2) Continuous duty
Multi-Stage Pump Specifications:
Operating limits:
1.Liquid temperature up to 60ìC
2.Ambient temperature up to 40ìC
3.Total suction lift up to 9meters
4.Continuous duty
Motor:
1.Two-pole induction motor( n=2900rpm)
2.Insulation Class F
3.Protection IP44
4.Protected by thermal protector
Material:
1.Pump body: Cast iron
2.Impeller: stainless steel
3.Motor housing: Aluminium
4.Shaft: Stainless iron
5.Mechanical sealing: Graphite/Ceramic
6.Bearing: NSK original in Japan/Made in China
Application:
-Centrifugal vertical multistage water pumps able to develop high pressure and a high water lift with a comparatively low power consumption
-Universal pump for civil and industrial purposes,for high pressure system and for irrigation in agriculture and pool fittings.
MODEL | POWER | MAX HEAD (M) | MAX FLOW (L/min) | MAX SUC.DEPTH (M) | IMPELLERS (PC) | QTY/20”CTR (PC) | |
KW | HP | ||||||
HMC-2SA | 0.37 | 0.5 | 25 | 90 | 9 | 2 | 2600 |
HMC-3SA | 0.55 | 0.75 | 35 | 100 | 9 | 3 | 2500 |
HMC-4SA | 0.75 | 1.0 | 45 | 110 | 9 | 4 | 2300 |
HMC-5SA | 0.9 | 1.2 | 55 | 120 | 9 | 5 | 2000 |
