4SD2 Series Deep Well Submersible Pump

Specifications

Deep Well Submersible Pump
1. for domestic use, for civil and industrial applications
2. for water supply from wells

Deep Well Submersible Pump Specification:



Operating conditions:
-Liquid temperature up to 40^oC
-Submersion depth 40m
-Minimum internal diameter of well: 102mm.
-Continuous duty.

Motor:
-Tow-pole induction motor (n=2850r.p.m)
-Built-in over load motor protector
-Insulation Class B/F
-Protection IP68

Material:
-External pump body: Stainless Steel
-Suction strainer: Stainless Steel
-Impeller and diffusors: Noryl
-Bearing brackets: Brass
-Shaft: Stainless Steel
-Motor housing: Stainless Steel
-Mechanical seal: Ceramic/Graphite

Application:
-Multistage submersible water pumps with radial closed impeller conceived in order to solve any problem of clean water conveyance.
-Suitable for irrigation, and pressure systems and pressure systems and generally for civil and industrial purposes.
