Garden submersible pump with booster system
Garden submersible pump with booster system
Technical Data
MODEL |
POWER (W) |
MAX HEAD (M) |
MAX FLOW (L/H) |
MAX SUB. DEPTH (M) |
P(min/max) |
CABLE AND LENGTH (M) |
QTY/20CTN (PC) |
TP03117 |
600 |
35 |
2800 |
7 |
2/3bar |
H05RN-F3G0.75mm2X10m |
380 |
TP03118 |
800 |
40 |
3200 |
8 |
2/3bar |
H05RN-F3G0.75mm2X10m |
380 |
TP03119 |
1000 |
44 |
3500 |
8 |
2/3bar |
H05RN-F3G0.75mm2X10m |
380 |
TP03120 |
1200 |
48 |
3800 |
8 |
2.5/4bar |
H05RN-F3G1.0mm2X10m |
380 |
Component
.pump
.pump body
Material
.pump body:pp
.Impeller: PP/stainless steel
.Shaft with rotor: 45# Carbon Steel/Stainless iron
Feature
.For clean water
.Insulation Class B/F
Application
.on the surface near the swimming pool
.Submersible dirty water pumps with back impeller suitable to lift waste liquids even with suspended solids
. Able to drain infiltrating water, cesspools or reservoirs, decanting water and clean, dirty or muddy swimming pools.
Operating limits
. Fluid temperature up to 35°C
. Maximum ambient temperature 40°C
