Mine Small Hydraulic Cylinder
US$ 1,080 - 12,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Splitting
Motor Type:
Other, For 4 type engine
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou or Other ports in China(mainland)
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Mine Manual Outdoor SplitterUS$ 1,080 - 12,000MOQ: 1 Set -
Efficient Driven Hydraulic Drive Water PumpUS$ 700 - 3,300MOQ: 1 Set
-
Lightest Small Gas ChainsawUS$ 2,000 - 3,000MOQ: 1 Set
-
Stable Air Compressor For Jack HammerUS$ 1,000 - 30,000MOQ: 1 Set
-
Hydraulic Breaker BracketUS$ 1,000 - 1,250MOQ: 1 Set
Condition
New
Application
Splitting
Motor Type
Other, For 4 type engine
Power(W)
Dieferent Engine
Place of Origin
Fujian, China
Brand Name
DSL
Model Number
DS90
Dimension(L*W*H)
150~380mm
Certification
ISO9001
Warranty
None
After-sales Service Provided
No overseas service provided
Mine Small Hydraulic Cylinder
Product Description
The hydraulic rock splitter is a kind of hand-hold splitting and demolition tool.It can controllably split rock or concrete.Especially suit for cabined area where large machine can not work.Such as hydraulic breaker and place where is strictly limited of noise,dust,flying debris,shake,exhaust gas,also widely use in the place where need non-explosive and blast forbidden.
| Engine type | Specifications (MM) |
Weight (KG) |
Fuel tank capacity(L) | Working medium |
Engine power |
Working pressure (Mpa) |
Work flow (L/Min) |
Configurable splitting machine number |
| Electric type | 384*280*620 | 75 | 30 | 46 or 68 anti-wear hydraulic oil | 0.75KW 2.2KW 4KW 7.5KW (380V) |
55~60 | 2.13 | 1 2~3 4~6 7~10 handle |
| Diesel type | 1150*1180*940 | 120 | 40 | 46 or 68 anti-wear hydraulic oil | 4.2KW | 55~60 | 2.13 | 1~10 handle |
| Gasoline type | 1200*1170*800 | 100 | 40 | 46 or 68 anti-wear hydraulic oil | 7.5HP | 55~60 | 2.13 | 1~10 handle |
| Pneumatic type | 364*280*620 | 100 | 40 | 46 or 68 anti-wear hydraulic oil | 4.04kw 5.5HP require compressor: 0.63mpa 4.8m3/min |
55~60 | 13 | 1~10 handle |
| Model | Drill hole diameter | pistion inner diameter | Minimum drill hole depth | length wedge | splitting distance | Splitting time | splitting force theoretical | splitting force effective | weight |
| (MM) | (MM) | (MM) | (MM) | (MM) | (S) | (T) | (T) | (KG) | |
| DS80A | Φ38~42 | 80 | ≥450 | 150 | 10~40 | 5~12 | 500 | 280 | 20 |
| DS80B | Φ40~42 | 80 | ≥500 | 200 | 10~40 | 5~12 | 600 | 300 | 21 |
| DS80C | Φ40~42 | 80 | ≥600 | 300 | 10~40 | 5~12 | 680 | 420 | 25 |
| DS80D | Φ45~48 | 80 | ≥800 | 450 | 10~40 | 5~12 | 720 | 450 | 27 |
| DS90A | Φ38~42 | 90 | ≥450 | 150 | 10~40 | 5~12 | 680 | 420 | 26 |
| DS90B | Φ40~42 | 90 | ≥500 | 200 | 10~40 | 5~12 | 720 | 450 | 26.5 |
| DS90D | Φ40~42 | 90 | ≥600 | 300 | 10~40 | 5~12 | 780 | 480 | 27 |
| DS90E | Φ45~48 | 90 | ≥700 | 380 | 10~40 | 5~12 | 820 | 500 | 28 |
