YT27 Pusher Leg Rock Breaking Hammer

Fuzhou Dig Sword Land Machine Co., Ltd.
YT27 Pusher Leg Rock Breaking Hammer thumbnail-1
YT27 Pusher Leg Rock Breaking Hammer photo-1
Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
DSL.
Model Number:
YT27
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
ALL port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name DSL.
Model Number YT27
Type Air Drill
Average Air Consumption 36.7Hz

Specifications

YT27 pusher leg rock breaking hammer
1)excellent working condition
2)well performanced
3)highly efficienctive

  YT27 pusher leg rock breaking hammer





Instruction

Air-leg Rock Drill is a kind of high efficiency air leg rock drill machine.



It is mainly used for blasting holes and other drilling works in a quarries, railway construction, water conservancy construction and national defence project facility.



When it is matched with Model FY250 Oil reservoir and Model FT160A or FT160B Air-leg , it is suitable for wet drilling under various of rocks at aclinic and incline orientation,it can also use in the trolley without Air-leg.





Specification

Weight27 kg
Outside dimension(L×W×H)668×248×202mm
Cylinder dia80mm
Piston stroke60mm
Impact energy≥75.5J
Impact frequencey≥ 36.9Hz
Air consumption≤83.3L/S
Air pipe (inner dia)25mm
Water pipe (inner dia)13mm
Air pressure0.63MPa
Water pressure0.3MPa
Bore dia34-45mm
Bore depth5m
Shank dimensions(hex×length)22×108±1mm/ 25×108±1mm
Model FY250B oil lubricator
Weight1.2kg
Oil capacity0.25L
Air legFT160AFT160B
Weight17kg16 kg
Llength:max3006mm2526mm
min1668mm1428mm
Propulsion stroke1338mm1098 mm
Axis thrust (max)2000N2000N









YT27 pusher leg rock breaking hammer



YT27 pusher leg rock breaking hammer





YT27 pusher leg rock breaking hammer



If you interested in our products, you can feel free to contract with us!
