Air Leg/pusher Leg Jack Hammer YT27

Fuzhou Dig Sword Land Machine Co., Ltd.
Air Leg/pusher Leg Jack Hammer YT27 thumbnail-1
Air Leg/pusher Leg Jack Hammer YT27 photo-1
Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
DSL.
Model Number:
YT27
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
ALL port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name DSL.
Model Number YT27
Type Air Drill
Average Air Consumption 36.7Hz

Specifications

Air leg/pusher leg jack hammer YT27
1)excellent working condition
2)well performanced
3)highly efficienctive

 Air leg/pusher leg jack hammer YT27





Instruction

Air-leg Rock Drill is a kind of high efficiency air leg rock drill machine.



It is mainly used for blasting holes and other drilling works in a quarries, railway construction, water conservancy construction and national defence project facility.



When it is matched with Model FY250 Oil reservoir and Model FT160A or FT160B Air-leg , it is suitable for wet drilling under various of rocks at aclinic and incline orientation,it can also use in the trolley without Air-leg.





Specification

Weight27 kg
Outside dimension(L×W×H)668×248×202mm
Cylinder dia80mm
Piston stroke60mm
Impact energy≥75.5J
Impact frequencey≥ 36.9Hz
Air consumption≤83.3L/S
Air pipe (inner dia)25mm
Water pipe (inner dia)13mm
Air pressure0.63MPa
Water pressure0.3MPa
Bore dia34-45mm
Bore depth5m
Shank dimensions(hex×length)22×108±1mm/ 25×108±1mm
Model FY250B oil lubricator
Weight1.2kg
Oil capacity0.25L
Air legFT160AFT160B
Weight17kg16 kg
Llength:max3006mm2526mm
min1668mm1428mm
Propulsion stroke1338mm1098 mm
Axis thrust (max)2000N2000N









Air leg/pusher leg jack hammer YT27



Air leg/pusher leg jack hammer YT27





Air leg/pusher leg jack hammer YT27
