Home > Manufacturing & Processing Machinery > Drilling Rig > Mine Drilling Rig > Hand Hold Pneumatic Stone Drill Machine Supplier
US$ 90 - 500
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Rotary Drilling Rig
Power Type:
Other, Pneumatic
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou or Other ports in China(mainland)
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Practical YT27 Pneumatic Jack Leg Rock Drill MachineUS$ 90 - 500MOQ: 1 Set -
New Model Patent S250 Quarry Air Rock Drill MachineUS$ 90 - 500MOQ: 1 Set
-
YSP45 Stopper Air Leg Rock Drill Crush UpwardsUS$ 90 - 500MOQ: 1 Set
-
Portable Y018 Hand Hold Air Rock Drill MachineUS$ 90 - 500MOQ: 1 Set
-
Pneumatic Portable Yo18 Hand Hold Jack HammerUS$ 90 - 500MOQ: 1 Set
Condition
New
Type
Rotary Drilling Rig
Power Type
Other, Pneumatic
Place of Origin
Fujian, China
Brand Name
DSL
Model Number
Y26
Usage
Coal
Voltage
Pneumatic Engine Driven
Power(W)
None
Dimension(L*W*H)
650*534*125 MM
Weight
26KG
Certification
ISO CE
Warranty
None
After-sales Service Provided
No overseas service provided
Product Description
Y26 type hand-hold rock drill is used at mines,Railway,irrigation and quarrie to digging holes and for the second digging holes.It can be used be used to digging dry or wet by horizontal holes,vertical holes or angling holes on medium-hard rock or hard rock.
| Weight | 26 | KG |
| Outside dimensions(L×W×H) | 650*534*125 | MM |
| Cylinder diameter | 65 | MM |
| Piston Stroke | 70 | MM |
| Working Pressure | 0.4 | Mpa |
| Impact energy | ≥30 | J |
| Impact frequency | ≥23 | HZ |
| Air consumption | ≤47 | L/S |
| Idling rotational speed | ≥200 | R/min |
| Noise | ≤124 | dB(A) |
| Working water pressure | 0.3-0.35 | Mpa |
| Air pipe inner diameter | 19 | MM |
| Water pipe inner diameter | 13 | MM |
| Rock drill hole diameter | 34-42 | MM |
| Rock drill hole depth | 5 | M |
| Shank Size | 22*108 | MM |
