Specifications
2kw Wind Turbine- Noisy level< 30db
- Working wind: 3-25 m/s
- Maglev Designed
- CE ,OEM.
2kw Wind Turbine
Model: TECHVH2KW/3KW
Vertical Axis Wind Turbine 1-5kw
WE ARE LOOKING FOR DISTRIBUTORS ...
Model:TECHMLV5kw/3kw 220v/360VDC system
220VDC /Off-grid Designed system
360VDC /On-grid Designed system
Advantages
---Magnetic Levitation designed generator
---Low noise, below 40db, less noisy
---high efficiency,less vibration
---Lower price, much popular designed style
System Composition
- Wind turbine + Blades Assembly
- Free-stand Mast (Hot galvanized 8m, steel tower)
- Off-grid Controller + Battery + Inverter + User Loads
TECHMLV5KW PHOTO
Model | TECHMLV 5kw |
Rotor Diameter (m) | 4.0 |
Material of blades and No. | RFP/ 5 pcs |
Rotation per minute for generator (rpm) | 150 -170rpm |
Working wind speed (m/s) | 3-25 |
Cut-in wind speed (m/s) | 3 |
Rated wind speed (m/s) | 11 |
Survival wind speed (m/s) | 50 |
Rated output power at rated wind speed (kw) | 5kw |
Maximum output power (kw) | 7kw |
Rated output voltage (V) | DC 380V/220V |
Generator type | PMG 3 phs, AC output |
Suggestion battery | 12v 150ah, 18 pcs |
Warranty | Two years for Generator, one year for spare parts |
Our homepage:
- We, Techwellpower is one of the leading suppliers of residential maglev vertical wind turbine from China with more than 10 years of experience.
- Our wind turbines have been installed in around 50 countries with more than 50 stable globle market customers. Techwellpower is capable to put the wind work for you with very low cost.
- Our VAWT ranges from 500w - 5000w, in name of the model of TECH 300w -5kw, TECHMLV3kw/5kw, TECHVH2kw, both on-grid and off-grid system available.
- At techwellpower, we take pride of offering advanced products that let homewoners and business partiners generate their own clean energy.
- Our VAWT is designed considering harsh climate, they are built simply and ruggedly to quietly last. Our machines have a large wind swept area to capture more wind and produce more energy, especially in low wind speed . These machines produce energy in the wind you get, day in and day out, power when you need, not just in wind storms.
-Detailed information please contact us at anytime.
Welcome to Techwellpower !
Following is 5kw ON-grid Inverter/ Controller/Dump load for the generator:
