Specifications
vertical axis wind turbine-50m/s security wind speed
-Noisy below 30db
-Maglev designed
-CE OEM Provided
Vertical axis wind turbine
- Super Silent Model: TECHMLV3kw/5kw
220v/360VDC output generator
-220VDC /Off-grid system
-360VDC /On-grid system
LOOKING FOR DISTRIBUTORS WORLD AROUND ...
Advantages
---Magnetic Levitation designed
---Less noisy below 30db
---High efficiency, less vibration
---Free maintainence
System Composition
- TECHMLV wind turbine + Blades Assembly
- Free-stand Mast (Hot galvanized 8m~12m height) or Guy cable tower
- Off-grid Controller + Battery + Inverter + Loads/user
Detailed specification as below:
Model | TECHMLV 5kw |
Rotor Diameter (m) | 4 |
Material of blades and No. | RFP/ 5 |
Rotation per minute for generator (rpm) | 150-170rpm |
Working wind speed (m/s) | 3-25 |
Cut-in wind speed (m/s) | 3 |
Rated wind speed (m/s) | 10m |
Survival wind speed (m/s) | 50 |
Rated output power at rated wind speed (kw) | 5kw |
Maximum output power (kw) | 7kw |
Rated output voltage (V) | DC 360V/220V |
Generator type | PMG 3 phases AC |
Suggestion battery | 12v 200ah 18 pcs |
Warranty | Two years since delivery |
http//
About Us:
We assure the best price among Maglev VAWTs around world.
- We, Techwellpower is one of the leading manufacturers for residential maglev vertical axis wind turbine in China .
- Our wind turbines have been installed in around 50 countries with more than 50 stable international customers. We are capable to put the wind working for you with higher efficiency and lower cost.
- Our VAWT turbine ranges from 500w up to 10000w, in name of the model of TECHMLV3kw/5kw/10kw, TECHVH2kw, both on-grid and off-grid system are available.
- In techwellpower, we are proud of offering advanced technical products which make homewoners and business generate their own clean and renewable power.
- Techwellpower Maglev VAWTs are designed for harsh climate, they are built simply and ruggedly to quietly last. Our machines have a large wind swept area to capture much wind and produce more energy, especially in low wind speeds. These machines generate energy in the wind you get, day in and day out, power when you need it.
Welcome to visit our company in China...
On-Grid Controller/Dump/Inverter
