Help CenterSuper Mini 1channel Video With One Return RS485 PTZ Camera to Fiber Optical Transmitter and Receiver 12V DC
Related Products
-
Super Mini Digital Video/ Data Fiber Optical Transmitter and ReceiverNegotiableMOQ: 1 Pair -
MINI 1Ch Digital Video/Audio/Data Fiber Transmitter and ReceiverNegotiableMOQ: 1 Pair
-
Analog Video+analog Audio Fiber Optical Transmitter and ReceiverNegotiableMOQ: 1 Pair
-
4channels XLR Balanced MONO Audio Fiber Optic Transmitter and ReceverNegotiableMOQ: 1 Pair
-
4channels XLR Balanced Stereo Audio Fiber Optic Transmitter and ReceverNegotiableMOQ: 1 Pair
BRIEF INTRODUCTION
DLX-DVOP01 MINI series of products provide uncompressed high quality transmission systems for 1 channels of digitalized analog video, 1channels of single-direction or bi-directional data and audio signals over one single mode or multimode optic fiber, DLX-DVOP01M is a multi-function product which based on highly reliable large-scale specialized ICs designed by ourselves. It's extremely flexible with the ability to add/drop video, audio, RS232/RS422/RS485, E1, 100M Ethernet ports via plugging in/out our field-proven service cards. Compared with the same kind of analog transmission systems that employ accidental amplitude or frequency modulation, DLX-DVOP01M products provide better transmission in quality.
The various types of DLX-DVOP01M products can meet different user's demands. Adopts advanced digital fiber optic transmission technologies, DLX-DVOP01M devices can be installed rapidly without customer adjusting, and they are easy to operate and maintain. On the front panel of the products are video connector (BNC), audio and data connector (RJ45 or Terminal Plug with screw clamps), and fiber optic connector (FC-single mode or SC-multimode). Users can easily monitor the status of power supply, connection and channels by the indicator lights. There are two types of DLX-DVOP01M available: standalone and card type.
APPLICATIONS
● High Way & Toll Station Surveillance
● Public Security Surveillance
● Surveillance and cable TV system
● Intelligent traffic monitoring system
● High Quality Video Conference
● Broadcast and TV program transmission
● Long-distance multimedia teaching
● Industrial Closed Circuit Television Surveillance
FEATURES
● One multimode or single mode fiber
● Modularized and industrialized design ensuring reliability and flexibility
● Large capacity of gigabit optical fiber transmission allowing of easy upgrade
● 10 digit coding and non-compression video transmission
● Large-scale Proprietary IC Core
● Auto PAL/NTSC/SECAM Compatible
● Support 24bits DVD format, High Dynamic Range video and Stereo audio
● Multi-services Flexible Configuration on the Same Platform
● Indicators for Power Supply, Video, Optic-link and Data-loop
● Free from In-field Adjustment
● Flexible and Easy Mount
● Protection against lightening strike and surge
● Transmission distance: 2KM(multi-mode),20km,40km,60km,80KM,100km optional (Single-mode)
SPECIFICATIONS
● Video
Channel : 1
Connector: BNC
Bandwidth: 8MHz
Quantization: 10 bits
DG: 1% typical
DP: 1 typical
SNR: >67dB
● Audio
Audio Input/output impedance: 600ohm(balanced) or 1000ohm(unbalanced)
Digitization: 24bit
Bandwidth: 20Hz to 20KHz
Nonlinear distortion coefficient: ≤ 1%
SNR: >85dB
Connector: Terminal Plug with screw clamps/RCA
● Data
Interface Type: RS-232/485/422, Manchester, Biphase
Operation Mode: Full-duplex/Half-duplex
Date Rate: DC-384Kbps/DC-2Mbps
BER:
Connector: RJ45/ Terminal Plug with screw clamps
● Environmental
Operation temperature: -30℃~+75℃
Storage temperature: -40℃~+85℃
Relative humidity: 0-95% Non-Condensing
MTBF: ≥10e5 hours
Power Supply: AC 100V~260V
