Filtration Geotextile with Three-Dimensional Drainage Net
Filtration Geotextile with Three-Dimensional Drainage Net Introduction:
3D Drainage Net Geotextile a unique three-dimensional double-sided sticky geonet and nonwoven geotextile made of. Integration of geotextiles (filtration effect) and geonet (drainage and reinforcement effects), played a "filtration - Drainage - to protect" the overall effect. Unique three-dimensional three-dimensional composite drainage network structure, in the course can withstand high pressure loads, and can maintain a considerable thickness, high tensile strength, corrosion resistance, acid and alkali, drainage capability, which provides a very high hydraulic conductivity
Filtration Geotextile with Three-Dimensional Drainage Net Feature:
1.Good water permeability
2.Corrosion resistance
3.Microbial resistant
4.Good permeability
5.Good water conductivity
6.High tensile strength
7.Strong resistance to deformation
8.The mesh is not easily blocked
9.Excellent drainage performance
10.Anti-aging,anti-acid and alkali
11.Can accommodate irregular deformations
12.Creep, corrosion and abrasion resistance
13.Safe and easy for construction
Filtration Geotextile with Three-Dimensional Drainage Net Index:
Unit |
|
||||||
1200g |
1400g |
1600g |
1800g |
2000g |
|||
1 |
Compound Weight of Unit Area |
g/m2 |
≥1200 |
≥1400 |
≥1600 |
≥1800 |
≥2000 |
2 |
Compound Thickness |
mm |
≥6.0 |
≥7.0 |
≥8.0 |
≥9.0 |
≥10.0 |
3 |
Compound Tensile Strength |
KN/m |
≥16.0 |
≥16.0 |
≥16.0 |
≥16.0 |
≥16.0 |
4 |
Compound Hydraulic Conductivity |
m2/s |
≥1.2×10-4 |
≥1.2×10-4 |
≥1.2×10-4 |
≥1.2×10-4 |
≥1.2×10-4 |
5 |
Net and Non-woven Geotextile Peel Strength |
KN/m |
≥0.3 |
≥0.3 |
≥0.3 |
≥0.3 |
≥0.3 |
6 |
Net Thickness |
mm |
≥5.0 |
≥5.0 |
≥6.0 |
≥7.0 |
≥8.0 |
7 |
Net Tensile Strength |
KN/m |
≥13.0 |
≥15.0 |
≥15.0 |
≥15.0 |
≥15.0 |
8 |
Non-woven Geotextile Weight of Unit Area |
g/m2 |
≥200 |
≥200 |
≥200 |
≥200 |
≥200 |
9 |
Non-woven Geotextile Permeability |
cm/s |
≥0.3 |
≥0.3 |
≥0.3 |
≥0.3 |
≥0.3 |
10 |
Width |
m |
2.1 |
2.1 |
2.1 |
2.1 |
2.1 |
11 |
Roll Length |
m |
30 |
30 |
30 |
30 |
30 |
