3 Layers Tri-dimension Composite Geonet

Name: 3 Layers Tri-dimension Composite Geonet
Brand: Starring
SKU: 142588516
Availability: InStock

US$ 1.96 - 2.05 MOQ: 5000 Square Meters

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Starring

Laiwu Starring Project Material Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name Starring

3 Layers Tri-dimension Composite Geonet

Composite Geonet Product Description

Product Description

Tri-dimension composite geonet is a chemically resistant composite comprised of a

three-dimensional extruded polyethylene geonet core, thermally laminated to non-woven geotextiles on either one or both surfaces.

Product Features

Cost-effective substitute for thick layers of coarse-grained soil in drainage applications, providing savings on materials, transportation installation and airspace.
Preserves aggregate resources for structural applications where alternative materials can’t be used.
Three functions in one unit: filtration, drainage and protection.
Rapid installation in comparison to conventional soil drainage layers.
Wide range of product combinations allows performance driven product selection at an economical price.
Chemically resistant polyethylene geonet and polypropylene geotextile construction provides long life in harsh environments.
Exhibits good interface shear strength with adjacent geomembranes and soil, allowing a high factor of safety against sliding

Product Applicationrange

In landfill cover systems geocomposites are used to drain surface water away from the

barrier layer decreasing percolation of water into the waste. geocomposites may also

be used as a gas venting layer below the barrier layer to prevent the build-up of gases

generated by degrading waste or underlying soils.

In landfill bottom liner systems geocomposites are used above the primary liner for

leachate drainage and as a leak detection layer between the primary and secondary

liners. Similarly, in liquid impoundments gecomposiye Drain may be used underneath

the primary liner as the leak detection layer.

Composite Geonet Product Technical Parameters

Item			unit		Value
Unit weight			g/m²		750		1000		1300		1600
thickness			mm		5.0		6.0		7.0		7.6
Hydraulic conductivity			m/s		K×10-4		K×10-4		K×10-3		K×10-3
Elongation			%		<50
Net tensile strength			KN/m		8		10		12		14
geotextile unit weight	PET needle punched geotextile	g/m²		200-200		200-200		200-200		200-200
	Filament non woven geotextile
	PP high strength geotextile
Tri-dimenstional tensile strength	PET needle punched geotextile	KN/m		18		20		22		25
	Filament non woven geotextile			30		35		38		40
	PP high strength geotextile			35		38		40		45
Peel strength between geotextile and geonet			KN/m		3
