Specifications
customized geotextile sheetMaterial:PP/PET
Width:1-6m
Weight:100-1200gsm
anti-aging,anti-acid and alkali,abrasion res
customized geotextile sheet
customized geotextile sheet Introduction:
customized geotextile sheet can be made of polypropylene (PP) or polyester(PET), The weight is available from 100G/M2 to 1200G/M2 and the width from 1m to 6m, Two kinds of processing technical to select: Needle punched and thermally bonded. Long fiber or short fiber. All kinds of colors are available. Our annual production ability is 20 million square meters.
customized geotextile sheet is widely known as earthwork material and industry fabric, used in the areas of railway, highway, water conservancy, dam, tunnel, subway, environment protection and so on.
customized geotextile sheet Feature:
- 1. Can withstand construction installation stresses
- 2. UV (Ultra Violet) Stabilized
- 3. High Chemical Resistance
- 4. Optimum Elongation
(+1) Cushioning - effective and low cost protection to membrane from damage by sharp objects.
(2) Drainage - allows subsurface water to pass to drain system while preventing soil from clogging system.
(3) Separation - applied to soft or saturated subgrade, prevents aggregate and ballast from mixing into subgrade.
(4) Filtration - geotextiles can provide collection and transfer of liquids and gases that build up and accumulate beneath geomembranes.
(5) Reinforcement - geotextiles can help relieve hydrostatic pressure beneath hard armor such as highways.
customized geotextile sheet Parameter Index:
| Density |
Thickness |
Breaking Strength |
Elongation of Fracture |
Tearing Strength |
CBR Bursting Strength |
Vertical Penetration Parameter |
Equivalent Aperture |
| g/m2 |
mm |
KN/m |
% |
KN |
KN |
cm/s |
O 95 mm |
| 100 |
0.9 |
2.5 |
25 ~ 100 |
0.08 |
0.3 |
K x (10 -1 ~ 10 -3) (K = 1.0 ~ 9.9) |
0.07 ~ 0.2 |
| 150 |
1.3 |
4.5 |
0.12 |
0.6 |
|||
| 200 |
1.7 |
6.5 |
0.16 |
0.9 |
|||
| 250 |
2.1 |
8.0 |
0.20 |
1.2 |
|||
| 300 |
2.4 |
9.5 |
0.24 |
1.5 |
|||
| 350 |
2.7 |
11.0 |
0.28 |
1.8 |
|||
| 400 |
3.0 |
12.5 |
0.33 |
2.1 |
|||
| 450 |
3.3 |
14.0 |
0.38 |
2.4 |
|||
| 500 |
3.6 |
16.0 |
0.42 |
2.7 |
|||
| 600 |
4.1 |
19.0 |
0.46 |
3.2 |
|||
| 800 |
5.0 |
25.0 |
0.60 |
4.0 |
