Specifications
10 oz geotextile fabricMaterial:PP/PET
Width:1-6m
Weight:100-1200gsm
anti-aging,anti-acid an
10oz geotextile fabric
10 oz geotextile fabric Description
Our Needle-Punched geotextile fabric is made up of tangled threads of 100% polypropylene, which give it superior strength to stand up to the stresses of construction and installation. It's resistance to UV and natural degradation provides a long lasting economical product.
10 oz geotextile fabric Features:
1.Geotextile has good air permeability and water permeability which can pass the water out and intercept the sand running-down
2.Geotextile has high water diversion property, it can form drainage passageway, transpire the surplus liquid and gas
3.Geotextile has high water permeability even under the pressure of soil and water
4.Geotextilecan spread, transfer or decompose the concentrate stress effectively to avoid the soil be damaged by outside affection
5.To prevent the freestone upper and lower level, soil and concrete mixed
6.Polypropylene fiber or polyester fiber and other chemical fiber as raw material, acid-alkali-proof, non-corrording, non warm-eaten,antioxidant
7.Light weight, convenient to use, easy construction, shorten working-period, increase economic efficiency
8.Make use of geotextile to strengthen the tensile strength and anti-deformation property of soil, increase the stability of building structure, and also improve the soil quality
10 oz geotextile fabric Application:
1. Construction fabric and road bed cloth using for road/rail way/high way ;
2. Filter projects underlay fabric;
3. Water project underlay matting fabric and bank protection;
4. Agriculture using, such as irrigation projects matting fabric, vegetables shelters protection and to be used as geo bags, growing bags etc.;
5. Medical using: surgical gowns, protective clothing, disinfection pack cloth, mask, diapers, cleaning cloth, wipe, wet face towels, magic towels, soft towels,feminine hygiene and disposable healthy cloth etc.;
6. Industry using: water proofing fabric, reinforced material, filter material, automobile decorating cloth, insulation materials, cement bag, etc.;
7. Garment lining, fusible interlining, shoulder pads, sleeve article cage, shoes lining fabric, hat lining, bag lining etc.;
10 oz geotextile fabric Technical parameters
Item |
Units |
Indicators |
||||||||||||
Per unit area |
g/m2 |
100 |
150 |
200 |
250 |
300 |
350 |
400 |
450 |
500 |
600 |
800 |
||
Thickness |
mm≥ |
1.9 |
1.3 |
1.7 |
2.1 |
2.4 |
2.7 |
3 |
3.3 |
3.6 |
4.1 |
5 |
||
Tensile Strength |
KN/m≥ |
2.5 |
4.5 |
6.5 |
8 |
9.5 |
11 |
13 |
14 |
16 |
19 |
25 |
||
Elongation |
%≥ |
25--100 |
||||||||||||
CBRbursting Strength |
KN≥ |
0.3 |
0.6 |
0.9 |
1.2 |
1.5 |
1.8 |
2.1 |
2.4 |
2.7 |
3.2 |
4 |
||
Equivalent aperture(O90) |
mm |
0.07--0.2 |
||||||||||||
Vertical permeability |
cm/s |
KX(10-9~10-12 ) K=1.0~9.9 |
||||||||||||
Tear Strength |
KN≥ |
0.08 |
0.12 |
0.16 |
0.20 |
0.24 |
0.28 |
0.33 |
0.38 |
0.42 |
0.46 |
0.6 |
||
