PVC Waterproof Membrane with High Quality

Specifications

1.High UV-resistant
2.High tensile strength and long-term flexibility
3.Dirt resistance

PVC Waterproof Membrane

homogeneous non-composite membranes (PVC-H)



1. Products Description

   The PVC waterproofing rolls formulas are based upon polyvinyl chloride resin with other assistants added to provide flexibility and stability such as anti-oxidant,absorbent of ultraviolet light, plasticizer and plastic filling agent.

   PVC waterproofing membrane is a highly-engineered,new-type membrane manufactured using polyvinyl chloride as main materials and added other chemicals such as anti-oxidant,anti-UV materials to make it flexible,stable and UV-resistant.



2. Product Features

  1.Excellent weathering characteristics,

  2.High tensile strength and long-term flexibility.

  3.Excellent resistance to harsh chemicals and industrial pollutants.

  4.Heat or solvent-welding effectively provides seamless roof coverings

  5.Can be choice for various methods of attachment and any shape of roof



3. Physical Properties

PVC Physical Properties GB/T 23260-2009

Item				Specification
				H	L	P	G	GL
The resin thickness of Middle fabric,mm≥				—		0.40
Tensile Properties		Maximum tension N/cm ≥		—	120	250	—	120
		Tension strength Mpa≥		10			10
		Maximum tension elongation%≥				15
		Fracture elongation,%≥		200	150		200	100
Heat treatment size change rate,%≤				2.0	1.0	0.5	0.1	0.1
Low-temperature bending				-25°CNo crack
Water tightness				0.3Mpa,2hNo seepage
Attack resistance				0.5kg·m,No seepage
static charge resistance						20kgNo seepage
Seam strip strength,N/mm≥				4.0orMembranes break		3.0
right-angle tear strength,N/mm≥				50			50
Trapezoid tear strength,N≥					150	250		220
Water absorption(70°C 168h)%			After soaking≤	4.0
			air-cure later≥	-0.40
Heat aging(80°C)	Time			672h
	Appearance			No blister,flaw,delamination,coherence,hole
	Tensile strength retention,%≥			85
	Elongation rate of keeping,%≥			80
	Low temperature bend			-20°CNo crack
Chemistry resistance	Appearance			No blister,flaw,delamination,coherence,hole
	Tensile strength retention%≥			85
	Elongation rate of keeping%≥			80
	Low-temperature bending			-20°CNo crack
Artificial weather accelerated aging	Time			1500hb
	Appearance			No blister,flaw,delamination,coherence,hole
	Tensile strength retention%≥			85
	Elongation rate of keeping%≥			80
	Low temperature bend			-20°CNo crack

4. Application Range

PVC waterproof membrane forms an effective barrier to liquid water or water vapor in the steel structure for industrial and civil engineering, underground engineering, such as subway , Bridges ,tunnel ,water pools, shelter, grain depot, land filling and subway.
